Page 1/7
Page 1 of 11
Assembly Instructions
Model: Jeep JL (Wrangler)
Description: MB Quart Jeep JL Wrangler 12” Subwoofer Enclosure
Part Number: MBQJL-302
MBQJL-302E - Unloaded Enclosure
Assembly Time: 90 Minutes (1.5-Hours)
No. Component Name Qty
1 Subwoofer Enclosure 1
2 ST4.2 x 19mm Screw 14
3 M6 x 60mm Flathead Screw 2
4 M6 x 60mm Bolt 2
5 7mm Rubber Plug 4
6 9mm Rubber Plug 2
7 L Bracket 2
8 M6 x 16mm Torx Screw 2
9 13 x 30mm Spacer 2
10 13 x 45mm Spacer 2
11 M6 Washer 2
12 68” Zip Tie
13 Grill 1
14 White Gasket 1
15 Wire Harness 1
1 Bojo or Panel Tool
2 T20 Torx Driver
3 T40 Torx Driver (Trailrail Equiped Only)
4 9/16” Drill Bit
5 Drill
6 4mm Allen Wrench
7 10mm Socket
Parts List
Tools Required
Before you begin, read through these instructions and check that all parts are
present. Please note that MB Quart cannot assume any responsibility for damage
resulting from incorrect installation.
Page 2 of 11
Disassembly Instructions
● Remove four T20 Torx screws
holding the subwoofer in the
enclosure. Then disconnect the
wiring from the subwoofer.
● Install four 7mm rubber plugs into
the inside of the enclosure.
● Install the white gasket material
into the channel of the grill.
Page 3 of 11
Disassembly Instructions
● Disconnect negative battery terminal
of the vehicle.
● If Trailrail equiped - remove three T40
screws and remove rail.
● If Trailrail ready - use panel tool to
unclip cover and remove.
● Using a panel tool carefully unclip the
tailgate panel and remove.
● With the tailgate panel laying face
down, drill two 9/16” holes at the
dimples at the bottom of the panel.
