Page 1/20
User Guide
5-Way Surge Protector
with Wi-Fi & Meter Reading
1300 002 534
Model: AP5W-0624
Product Code: 715900 06/2024
tempo.org/support
2
1
Have you got everything?
Unpack the box and make sure all
of these items are there:
Note: only one power board
(white/black) is supplied.
A. 5-Way Surge Protector with Wi-Fi &
Meter Reading
B. User Guide
C. Warranty Certiîž‚cate
3
2
Product Overview
Overload Circuit Breaker (Resettable)
Protects against current overload at 10 amp.
Power On/Off Switch
Press to supply/cut off power to the sockets.
Note: Please turn off “Child Lock” in the Tuya app to
unlock the power button.
Please use app to control the 5 independent
switches separately.
LED status Indicator
When the LED is blinking, it indicates that
Wi-Fi is in connection mode, “Easy Mode” -
(The LED blinks quickly) or “AP Mode” - (The
LED blink slowly).
When the LED is on, it indicates the Wi-Fi is
connected.
Surge Protected LED Indicator
When lit, the green light indicates that all
connected devices are surge protected.
AC Sockets
All 5 sockets are the same protected sockets
and can be used interchangeably.
When the LED is on, the socket is switched
on.
When the LED is off, the socket is switched
off.
Note: The USB A and USB C outputs are
always on.
USB-C and USB-A Charging Ports
For charging phones, tablets or other devices.
4
1
2
3
4
5
6
1
5
2
6
3
Product Specifications
