Page 1/3
AXLOC4M-80
INSTALL ATION INSTR UCTIONS
REV. 4/28/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The Line Output Converter (LOC) should be installed on a stereo’s speaker output
wires or the output wires on an OEM amplifier of up to 80 watts per channel.
These wires can be found behind the stereo in the dash, on the outside of an OEM
amplifier, or on the input terminals on the OEM speakers.
Wire color and function
The audio input wire colors are an EIA standard for car stereo applications as follows:
Note: Be sure that all audio input connections are polarized or in phase with each
other. That is, the positive output wires from the audio source need to be connected
to the corresponding positive input wires of the LOC. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
(Continued on other side)
Input harness
White Left front (+) input
White/Black Left front (-) input
Gray Right front + input
Gray/Black Right front (-) input
Green Left rear (+) input
Green/Black Left rear (-) input
Purple Right rear (+) input
Purple/Black Right rear (-) input
Power harness
Yellow Battery +12v input
Black Power (-) ground input
Blue Remote +12v output
Brown Reference ground (-)
AXLOC4M-80
INSTALL ATION INSTR UCTIONS
REV. 4/28/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The LOC is designed to convert (4) channels of speaker level audio into (4) channels
of line level audio. This allows for the installation of line level products such as
amplifiers, EQs and crossovers on systems that do not have RCA line level outputs.
In addition this device will also detect the presence of an audio signal and then
generate a +12V output that can be used to turn-on an aftermarket amplifier.
Features
80 watts maximum input
Input circuit corrects
Crossover distortion commonly found on other brands of LOCs
6:1 Step down with variable output
Gold flashed RCAs
Attractive and durable enclosure
Note: The LOC will shut off 60 seconds after no signal detected.
