AXCSD-6V
AXCSD-6V
I N S T A L L A T I O N I N S T R U C T I O N S
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/29/20 INSTAXCSD-6V
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/29/20 INSTAXCSD-6V
Product Info
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
12-volt to 6-volt
Step-Down Converter
Converts 12-volts DC to 6-volts DC to provide proper voltage for a 6-volt factory backup camera
• AXCSD-6V converter with wiring harness
AXCSD-6V
Connections
Black - Chassis ground
Blue/White - Reverse trigger*
Blue/Red - Camera power
*
Accessory power can also be used
if the radio has the option to monitor
the camera while in motion
