Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
WHITE = LEFT Front (+) Input
WHITE /BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK= RIGHT Front (-) Input
GREEN= LEFT Rear (+) Input
GREEN/BLACK = LEFT rear (-) Input
PURPLE= RIGHT Rear (+) Input,
PURPLE/BLACK = RIGHT Rear (-) Input
BLACK = Reference Ground (-)
(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the
audio source need to be connected to the corresponding positive
input wires of the AX-ALOC648. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and
low quality audio.
Adjusting the AX-ALOC648 for maximum performance:
After completing all of the necessary connections turn the AX-
ALOC648 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4
maximum volume. Select one of the adjustment pots on the AX-
ALOC648 and turn it slowly clockwise until you notice audio distor-
tion and then stop. Turn the remaining pot to the same position as
the previously adjusted pot. The audio set-up of the AX-ALOC648 is
now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
WHITE = LEFT Front (+) Input
WHITE /BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK= RIGHT Front (-) Input
GREEN= LEFT Rear (+) Input
GREEN/BLACK = LEFT rear (-) Input
PURPLE= RIGHT Rear (+) Input,
PURPLE/BLACK = RIGHT Rear (-) Input
BLACK = Reference Ground (-)
(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the
audio source need to be connected to the corresponding positive
input wires of the AX-ALOC648. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and
low quality audio.
Adjusting the AX-ALOC648 for maximum performance:
After completing all of the necessary connections turn the AX-
ALOC648 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4
maximum volume. Select one of the adjustment pots on the AX-
ALOC648 and turn it slowly clockwise until you notice audio distor-
tion and then stop. Turn the remaining pot to the same position as
the previously adjusted pot. The audio set-up of the AX-ALOC648 is
now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
WHITE = LEFT Front (+) Input
WHITE /BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK= RIGHT Front (-) Input
GREEN= LEFT Rear (+) Input
GREEN/BLACK = LEFT rear (-) Input
PURPLE= RIGHT Rear (+) Input,
PURPLE/BLACK = RIGHT Rear (-) Input
BLACK = Reference Ground (-)
(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the
audio source need to be connected to the corresponding positive
input wires of the AX-ALOC648. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and
low quality audio.
Adjusting the AX-ALOC648 for maximum performance:
After completing all of the necessary connections turn the AX-
ALOC648 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4
maximum volume. Select one of the adjustment pots on the AX-
ALOC648 and turn it slowly clockwise until you notice audio distor-
tion and then stop. Turn the remaining pot to the same position as
the previously adjusted pot. The audio set-up of the AX-ALOC648 is
now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
WHITE = LEFT Front (+) Input
WHITE /BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK= RIGHT Front (-) Input
GREEN= LEFT Rear (+) Input
GREEN/BLACK = LEFT rear (-) Input
PURPLE= RIGHT Rear (+) Input,
PURPLE/BLACK = RIGHT Rear (-) Input
BLACK = Reference Ground (-)
(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the
audio source need to be connected to the corresponding positive
input wires of the AX-ALOC648. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and
low quality audio.
Adjusting the AX-ALOC648 for maximum performance:
After completing all of the necessary connections turn the AX-
ALOC648 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4
maximum volume. Select one of the adjustment pots on the AX-
ALOC648 and turn it slowly clockwise until you notice audio distor-
tion and then stop. Turn the remaining pot to the same position as
the previously adjusted pot. The audio set-up of the AX-ALOC648 is
now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
WHITE = LEFT Front (+) Input
WHITE /BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK= RIGHT Front (-) Input
GREEN= LEFT Rear (+) Input
GREEN/BLACK = LEFT rear (-) Input
PURPLE= RIGHT Rear (+) Input,
PURPLE/BLACK = RIGHT Rear (-) Input
BLACK = Reference Ground (-)
(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the
audio source need to be connected to the corresponding positive
input wires of the AX-ALOC648. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and
low quality audio.
Adjusting the AX-ALOC648 for maximum performance:
After completing all of the necessary connections turn the AX-
ALOC648 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4
maximum volume. Select one of the adjustment pots on the AX-
ALOC648 and turn it slowly clockwise until you notice audio distor-
tion and then stop. Turn the remaining pot to the same position as
the previously adjusted pot. The audio set-up of the AX-ALOC648 is
now complete and ready to be enjoyed.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
WHITE = LEFT Front (+) Input
WHITE /BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK= RIGHT Front (-) Input
GREEN= LEFT Rear (+) Input
GREEN/BLACK = LEFT rear (-) Input
PURPLE= RIGHT Rear (+) Input,
PURPLE/BLACK = RIGHT Rear (-) Input
BLACK = Reference Ground (-)
(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or in
phase with each other. That is, the positive output wires from the
audio source need to be connected to the corresponding positive
input wires of the AX-ALOC648. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and
low quality audio.
Adjusting the AX-ALOC648 for maximum performance:
After completing all of the necessary connections turn the AX-
ALOC648 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and
adjust the main volume control on the stereo to approximately 3/4
maximum volume. Select one of the adjustment pots on the AX-
ALOC648 and turn it slowly clockwise until you notice audio distor-
tion and then stop. Turn the remaining pot to the same position as
the previously adjusted pot. The audio set-up of the AX-ALOC648 is
now complete and ready to be enjoyed.
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
The is designed to convert 4 channels AX-ALOC648
of speaker level audio to line level audio. This allows
for the installation of line level products such as
ampliers, EQs and crossovers on stereo heads that
do not have RCA line level outputs.
Features:
80 Watts maximum input, input circuit corrects
crossover distortion commonly found on other brands
of locs, 6:1 step down with variable output, detachable
input plug, gold ashed rcas, attractive & durable
enclosure.
4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER
The is designed to convert 4 channels AX-ALOC648
of speaker level audio to line level audio. This allows
for the installation of line level products such as
ampliers, EQs and crossovers on stereo heads that
do not have RCA line level outputs.
Features:
80 Watts maximum input, input circuit corrects
crossover distortion commonly found on other brands
of locs, 6:1 step down with variable output, detachable
input plug, gold ashed rcas, attractive & durable
enclosure.
4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER
The is designed to convert 4 channels AX-ALOC648
of speaker level audio to line level audio. This allows
for the installation of line level products such as
ampliers, EQs and crossovers on stereo heads that
do not have RCA line level outputs.
Features:
80 Watts maximum input, input circuit corrects
crossover distortion commonly found on other brands
of locs, 6:1 step down with variable output, detachable
input plug, gold ashed rcas, attractive & durable
enclosure.
4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER
The is designed to convert 4 channels AX-ALOC648
of speaker level audio to line level audio. This allows
for the installation of line level products such as
ampliers, EQs and crossovers on stereo heads that
do not have RCA line level outputs.
Features:
80 Watts maximum input, input circuit corrects
crossover distortion commonly found on other brands
of locs, 6:1 step down with variable output, detachable
input plug, gold ashed rcas, attractive & durable
enclosure.
4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER
The is designed to convert 4 channels AX-ALOC648
of speaker level audio to line level audio. This allows
for the installation of line level products such as
ampliers, EQs and crossovers on stereo heads that
do not have RCA line level outputs.
Features:
80 Watts maximum input, input circuit corrects
crossover distortion commonly found on other brands
of locs, 6:1 step down with variable output, detachable
input plug, gold ashed rcas, attractive & durable
enclosure.
4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER
The is designed to convert 4 channels AX-ALOC648
of speaker level audio to line level audio. This allows
for the installation of line level products such as
ampliers, EQs and crossovers on stereo heads that
do not have RCA line level outputs.
Features:
80 Watts maximum input, input circuit corrects
crossover distortion commonly found on other brands
of locs, 6:1 step down with variable output, detachable
input plug, gold ashed rcas, attractive & durable
enclosure.
4 CHANNEL, ADJUSTABLE LINE OUTPUT CONVERTER

Product Specifications

Brand: AXESS
Category: Not categorized
Model: AX-ALOC648

Do you need help?

If you need help with AXESS AX-ALOC648, ask a question below and other users will answer you


Not categorized AXESS User Manuals

AXESS

AXESS AXDSPX-BM1 Manual

25 October 2024
AXESS

AXESS AXDIS-BW122 Manual

13 October 2024
AXESS

AXESS 99-3303 Manual

13 October 2024
AXESS

AXESS AXBT-MZ2 Manual

13 October 2024
AXESS

AXESS AX-ALOC618 Manual

13 October 2024
AXESS

AXESS ANC-GMH3 Manual

13 October 2024
AXESS

AXESS ANC-GMH2 Manual

13 October 2024
AXESS

AXESS ANC-CHH2 Manual

13 October 2024
AXESS

AXESS AX-AB-CH3 Manual

13 October 2024
AXESS

AXESS AX-AB-CH4 Manual

13 October 2024

Not categorized User Manuals

Latest Not categorized User Manuals

NightStick

NightStick LGL-170A Manual

27 October 2024
Supermicro

Supermicro SuperServer ASG-2115S-NE332R Manual

27 October 2024
Phanteks

Phanteks Glacier R220C Manual

27 October 2024
Elac

Elac Protek PR-71S Manual

27 October 2024
NightStick

NightStick LGL-180-IR Manual

27 October 2024
United Office

United Office IAN 54183 Manual

27 October 2024
United Office

United Office IAN 066078 Manual

27 October 2024
United Office

United Office IAN 331845 Manual

27 October 2024
United Office

United Office ULGD 350 A Manual

27 October 2024
United Office

United Office UAVS 300 A1 Manual

27 October 2024
