Page 1/6
User Manual
Stereo Wireless Headphones
AH6B
Product Overview 1 ·····································································································································································
Basic Operation 1 ··········································································································································································
Status of LED indicators 2 ··························································································································································
Connect to a Bluetooth device 2 ·············································································································································
Connect to two Bluetooth devices simultaneously 3 ······································································································
Reconnect to Bluetooth device 3 ············································································································································
Connect to PC / Laptop 3 ···························································································································································
Using as a wired headphone 4 ·················································································································································
Charging 4 ·······················································································································································································
Reset 4 ·······························································································································································································
Troubleshooting 4 ········································································································································································
1
Product Overview
AUX
MUTE
Basic Operation
Button Function Operation
Power
Switch
Power ON Slide the power switch towards middle you’ll
hear “Welcome to Avantree”
Pairing
Slide the power switch to left and hold for 3
seconds. You’ll hear “Pairing” and the LED indicator
blinks and
RED BLUE alternately.
Power OFF Slide the power switch to right you’ll hear
“Good Bye”
Answer /
End a call Press once
Reject a call Hold 1s whilst a call coming
Activate smart
voice assistant Press twice
Micropahone
Mute ON/OFF
While on an active call, Press and hold 1s to
activate/close Microphone Mute function. You’ll hear
“Microphone Mute ON/OFF”
Track backward Press once
Play/Pause Press once
Track forward Press once
2
Volume
Wheel
Volume up Rotate the volume wheel forward to volume up
Volume down Rotate the volume wheel backward to volume
down
MUTE
Microphone
Mute ON/OFF
While on an active call with boom mic, Press and hold
MUTE
1s to activate/close Microphone Mute function.
You’ll hear “Microphone Mute ON/OFF”
&
Voice Prompt
ON/OFF Hold & till you hear “Voice Prompt ON/OFF”
Note: Functionality varies by application.
Status of LED indicators
Working Status LED indicator
Paring Mode Blinks BLUE & alternatelyRED
Reconnecting Blinks BLUE once every 1 second
Disconnected Blinks BLUE once every 10 seconds
Microphone Mute ON Remains RED
Connected Blinks BLUE once every 5 seconds
Low battery Blinks three times every 10 secondsRED
Connect to a Bluetooth device
Enter Headphones into Pairing Mode:
Slide the power switch to left and hold for 3 seconds. You’ll hear “Pairing” and the LED indicator blinks
RED and BLUE alternately.
Pair to mobile device
• Set the headphones into Pairing Mode as above.
• Activate Bluetooth on your phone and set it to search for new devices.
• Select “Avantree AH6B”, once successfully paired you’ll hear “connected”.
Product Specifications
| Brand: | Avantree |
| Category: | Headphones |
| Model: | AH6B |
