Audison Voce AV 5.1k HD Manual
Read below 📖 the manual in Italian for Audison Voce AV 5.1k HD (25 pages) in the Receiver category. This guide has been helpful for 4 people and has been rated 4.5 stars on average by 2 users
Page 1/25
USER’S
MANUAL
AV 5.1k HD
rev. 1.1
www.audison.eu
Index
1. INTRODUCTION ..................................................................................................................................................................................03
2. PACKAGING CONTENTS 04 ..................................................................................................................................................................
3. SAFE SOUND 05 .......................................................................................................................................................................................
4. GENERAL PRECAUTIONS .................................................................................................................................................................06
5. INSTALLATION .....................................................................................................................................................................................07
6. REAR PANEL 08 ........................................................................................................................................................................................
6.1 How to connect power cables 08 ..................................................................................................................................................
6.2 How to replace the fuse 09 .............................................................................................................................................................
6.3 How to connect the REMOTE IN (only with Audison bit One processor) 09 .........................................................................
7. FRONT PANEL 10 .....................................................................................................................................................................................
7.1 Control panel display 11 ..................................................................................................................................................................
7.2 How to connect the amplifier to an Audison bit Ten D processor 13 .....................................................................................
7.3 How to connect the amplifier to an Audison bit One processor 13 ........................................................................................
7.4 How to connect the amplifier to an Audison bit One HD processor 14 .................................................................................
7.5 How to configure AV bit IN HD 15 ..................................................................................................................................................
7.6 How to insert AV bit IN 16 ...............................................................................................................................................................
7.7 Full DA Example: Front + Rear + Sub with Audison bit Ten D processor 17 .........................................................................
7.8 Full DA Example: Woofer + Tweeter + Sub with Audison bit Ten D processor 18 ...............................................................
7.9 Full DA Example: Front + Rear + Sub with Audison bit One processor.............................................................................19
7.10 Full DA Example: Woofer + Tweeter + Sub with Audison bit One processor 20 ................................................................
7.11 Full DA Example: Front + Rear + Sub with Audison bit One HD processor 21 ...................................................................
7.12 Full DA Example: Woofer + Tweeter + Sub with Audison bit One HD processor 22 ..........................................................
8. TECHNICAL SPECIFICATIONS 23 ........................................................................................................................................................
USER’S MANUAL AV 5.1k HD
3
USER’S MANUAL
1. INTRODUCTION
Coming directly from the know-how of the exceptional Thesis line, Voce components takes the experience of listening in the
car to a new level of excellence.
Project innovation, advanced design, benchmark performance; the synthesis of consolidated know-how applied to car audio
systems. The Voce project was born to make Thesis sound quality available to a wider - but no less demanding - audience.
The development of these components took advantage of the major innovations introduced while designing the Thesis
line: analog and digital technologies combined using different classes of configuration for amplifiers, reduction of the main
sources of non-linear distortion, linearization of acoustic and electric loads, control of cone and diaphragm resonance for
speakers. To achieve these goals it was necessary to develop new circuit solutions, increase heat capacity, design new
moulds for baskets and diaphragms and define new assembly procedures and quality control.
A delicate balance of analysis and refinement led us to results exceeding our expectations and set a new benchmark for the
category.
THE AV 5.1K AMPLIFIERS PROJECT
AV 5.1k HD, 1650W (RMS) total, 5-channel power audio amplifier: hybrid design made up of two 75 W A Class channels, two
250 W AB Class channels and one 1000 W D Class channel.
This unique combination of technologies, each especially suitable for one specific audio section, makes the AV 5.1k HD
amplifier the perfect choice to build active two-way Front systems: Tweeter/MID-Tweeter (A Class) + Woofer (AB Class) e
Subwoofer (D Class), or Front + Rear + Subwoofer systems.
AV 5.1k HD is the first Car Audio amplifiers featuring digital inputs only, providing the ability to connect directly to the digital
outputs of a digital signal processor (DSP).
Through this connection, made via the Audison AD Link available on the Audison processors (bit One, bit Ten D), a Full DA HD
audio chain can be created. Thanks to this chain, the high resolution (96kHz/24 bit) digital audio signal coming from the
head unit, via the processor, can be obtained up to just the Digital/Analog converter of the amplifier’s audio chain, ensuring
maximum reduction of any signal deterioration.
Thanks to its input connectivity, the Audison AC Link can also be connected to control the amplifier as well as the AC Link
and AD Link outputs, to expand the audio system with other amplifiers.Audison Voce
These features make the most advanced amplifier available in the market, perfect to appreciate the quality of AV 5.1k HD
Hi-Res audio files.
AV 5.1k HD /
1
Product Specifications
| Brand: | Audison |
| Category: | Receiver |
| Model: | Voce AV 5.1k HD |
