Audison VOCE AV 3.0 Manual
Read below đ the manual in Italian for Audison VOCE AV 3.0 (20 pages) in the Speaker category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/20
AV 1.1 AV 3.0 AV 5.0 AV 6.5 AV X5 AV X6.5 AV 10 AV 12
28 66 103 130 103 130 208 260
- 2 3 3 3 3 14 15
3,3 3 3,5 3,5 3,5 3,5 3,7 3,7
1000 160 81 68 81 68 41 32
0,30 0,12 0,26 0,31 0,53 0,59 - -
0,03 0,07 0,17 0,17 - - - -
- 0,38 3,14 8,2 3,14 8,2 30,7 82,2
0,3 4,4 11,2 16,1 11,2 16,1 80,0 119,6
0,07 0,24 0,33 0,34 0,33 0,34 0,19 0,21
2,2 4,05 5,05 5,5 5,05 5,5 10,7 11,84
1,04 0,64 0,73 0,74 0,73 0,74 0,54 0,52
1,38 0,74 0,80 0,82 0,80 0,82 0,66 0,63
4,20 4,70 8,91 7,84 8,91 7,84 2,95 3,06
92 93 90 91 90 91 91 91
D
mm
Xmax
mm
Re
âŚ
Fs
Hz
Le
mH@1kHz
Le
mH@10kHz
Vas
l
Mms
g
Cms
mm/N
BL
T. m
Qts
Qes
Qms
Spl
dB
Electro - Acoustic parameters
OWNERâS MANUAL
www.audison.eu
COMP / SYSTEM / COAX / SUB
Tutte le speciďŹche riportate sono soggette a cambiamento senza preavviso / All SpeciďŹcations Subject to Change Without Notice
JBL005_REV.G
MANUALE DâUSO | OWNERâS MANUAL COMP / SYSTEM / COAX / SUB
Contenuto dellâimballo / Packaging contents
AV 1.1
AV K6
AV K5
AV 3.0 AV 6.5 optional
AV X6.5
optional
AV X5
optional
Gentile Cliente,
complimenti per aver acquistato un prodotto AUDISON VOCE. La vostra soddisfazione è il primo requisito cui
devono rispondere i nostri prodotti: la stessa soddisfazione di chiunque voglia vivere lâemozione del car audio.
GLI ALTOPARLANTI AUDISON VOCE SONO IN GRADO DI CREARE SISTEMI AUDIO AD ALTA POTENZA CHE
POSSONO GENERARE ELEVATISSIME PRESSIONI SONORE INDISTORTE. RICORDATE CHE PROLUNGATE
ESPOSIZIONI AD UN LIVELLO ECCESSIVO DI PRESSIONE ACUSTICA POSSONO PRODURRE DANNI AL
VOSTRO UDITO; UTILIZZATE DUNQUE EQUILIBRIO E BUON SENSO NELLâASCOLTO.
La sicurezza durante la marcia deve restare sempre al primo posto. In ogni situazione il volume dâascolto deve
avere un livello tale da non coprire i rumori provenienti dallâesterno; dovreste essere in condizione di udire anche
quelli del Vostro veicolo per affrontare prontamente situazioni di emergenza.
Per ottenere il massimo delle prestazioni dal Vostro nuovo componente. Vi consigliamo di seguire attentamente
le istruzioni del presente manuale. La realizzazione di un sistema hi-ďŹ car di alto livello richiede una buona
conoscenza delle problematiche meccaniche ed elettriche delle autovetture; qualora riteneste di non possedere
gli attrezzi necessari o la conoscenza adeguata, non esitate a contattare un installatore specializzato.
Unâinstallazione a regola dâarte Vi assicurerĂ prestazioni entusiasmanti e coinvolgenti, senza inďŹuire sulla
sicurezza e lâafďŹdabilitĂ della Vostra autovettura.
Questo manuale è stato redatto per fornire le indicazioni principali e necessarie allâinstallazione e allâuso del
sistema. La varietà delle applicazioni possibili è tuttavia molto ampia; per avere ulteriori informazioni non esitate
a contattare il Vostro rivenditore Audison o lâassistenza ufďŹciale Audison via mail, scrivendo direttamente agli
indirizzi:
Per lâItalia - supporto.tecnico@elettromedia.it
Dear Customer,
Congratulations on purchasing an product. Your satisfaction is the ďŹrst requirement that our AUDISON VOCE
products must meet: the same satisfaction as the one enjoyed by those who long for the car audio emotion.
THE AUDISON VOCE LOUDSPEAKERS ARE DESIGNED FOR HIGH POWER AUDIO SYSTEMS THAT
CAN GENERATE VERY HIGH UNDISTORTED SOUND PRESSURE. PLEASE REMEMBER THAT LONG
EXPOSURE TO AN EXCESSIVELY HIGH SOUND PRESSURE LEVEL MAY DAMAGE YOUR HEARING;
THEREFORE, PLEASE USE COMMON SENSE AND PRACTICE SAFE SOUND.
Safety must be at the ďŹrst place while driving. In every situation, the listening volume should not cover the noise
coming from outside the car; You should also be able to hear the noise generated by Your car in order to
promptly face any emergency.
In order to get the best performance from Your new speaker we recommend you carefully follow the instructions
herein. In order to make a top level car hi-ďŹ system, You need to know the car mechanical and electrical issues
very well; if You think You lack the required tools or the sufďŹcient knowledge, please contact a specialty installer.
A workmanlike installation will ensure You exciting, enthralling performance, without affecting Your carâs safety
and reliability.
This manual has been drawn to provide the main instructions required to install and use the system. However,
the range of possible applications is very wide; in order to get further information, please contact Your Audison
dealer or the Audison authorized service by sending an e-mail directly to the following email address:
Worldwide - support@elettromedia.it
AV 12 optional
optional
AV 10
32
MANUALE DâUSO | OWNERâS MANUAL COMP / SYSTEM / COAX / SUB
A C
D
B
Trim Ring
Montaggio in predisposizione / Factory cut-out mounting
Montaggio con supporto inclinato / Wedge mounting
Ingombro/ Size
60°
30°
Trim Ring
48 44,8 28 15,2 mm
A B C D
1â7/8 1â3/4 1â1/8 5/8â in.
AV 1.1
4 5
Product Specifications
| Brand: | Audison |
| Category: | Speaker |
| Model: | VOCE AV 3.0 |
