Elettromedia - 62018 Potenza Picena (MC) Italy - T +39 0733 870 870 - F +39 0733 870 880 - www.elettromedia.it
All specications subject to change without notice_13.C
www.audison.eu
AP4.9 bit
4 channel amplier featuring
9 channel built-in processor.
AP4.9 bit amplier was designed for the Integration into OEM front/rear systems where a lot of power is required. The
built-in processor, that this amplier shares with the AP8.9 bit, provides the ability to assign the pre-outs to the AP1 D
amplier to drive a subwoofer, to the AP4 D amplier to have 4 additional amplied channels exceeding 1080 W @ 4 - 2 Ω
total power.
AP5.9 bit
5 channel amplier featuring
9 channel built-in processor.
AP5.9 bit amplier is ideal to realize a classic front/rear plus subwoofer system using the fth mono channel
with
280 W @ 2 Ω
. The built-in processor, that this amplier shares with the AP8.9 bit, provides the ability to assign the pre-
outs
to the AP4 D amplier, creating a very powerful system in a small space thanks to the “rack mounting” system.
AP4 D
4 channel amplier.
AP4 D amplier was designed as an extension for the AP4.9 bit and AP5.9 bit ampliers, offering 4 additional
70 W @ 4 amplied channels.Ω
AP1 D
Mono amplier.
The AP1 D amplier was designed to drive a subwoofer; at 2 Ohms it is stable and can supply 520 W power.
SYSTEM COMBINATION
Model
AP8.9 bit + AP1 D
AP5.9 bit + AP4 D
AP4.9 bit + AP4 D + AP1 D
Power @ 4 Ω W (RMS)
35 x 8 + 300 x 1
20 x 2 + 50 x 2 +
70 x 4 + 140 x 1
70 x 4 + 70 x 4 + 300
Power @ 2 Ω W (RMS)
65 x 8 + 520 x 1
35 x 2 + 85 x 2 + 130 x 4 + 280 x 1
130 x 4 + 130 x 4 + 520
Max Power
@ 4 / 4-2 / 2 Ω W (RMS)
580 / 1040
580 / 700 / 1040
860 / 1080 / 1560
Max Power
@ 4/2 Ω W (mono) (RMS)
35 x 8 + 520 x 1
20 x 2 + 50 x 2 + 70 x 4 + 280 x 1
70 x 4 + 70 x 4 + 520
POWER COMPARISON TABLE
Model
AP8.9 bit
AP5.9 bit
AP4.9 bit
AP4 D
AP1 D
Power Ch
8
5
4
4
1
DSP Ch.
Yes (9)
Yes (9)
Yes (9)
No
No
Inputs
6 ch wired hi-lo level:
1) F/R + AUX Stereo
2) 2 Way F + R
3) F/R + Center + SUB
6 ch wired hi-lo level:
1) F/R + AUX Stereo
2) 2 Way F + R
3) F/R + Center + SUB
6 ch wired hi-lo level:
1) F/R + AUX Stereo
2) 2 Way F + R
3) F/R + Center + SUB
4 ch RCA / Wired
1 ch RCA / Wired
Pre Out
1 ch RCA x AP 1D
or SUB AMP
1 ch Wired x AP4D
or SUB AMP
1 ch Wired x AP1 D
4 ch Wired x AP4 D
1 ch RCA / Wired x AP 1 D
+
4 ch Wired x AP 4D
-
-
Power @ 4Ω W (RMS)
35 x 8
(4 to 7 bridgeable)
20 x 2 + 50 x 2 + 140 x 1
70 x 4
(2 to 3 bridgeable)
70 x 4
(2 to 3 bridgeable)
280 x 1
Power @ 2Ω W (RMS)
65 x 8
35 x 2 + 85 x 2 + 280 x 1
130 x 4
130 x 4
520 x 1
Max Power
@ 4/2Ω W (RMS)
280 / 520
280 / 520
280 / 520
280 / 520
280 / 520
