YR SERIES ICEMAKER END-USER MANUAL
In order to provide the best
service, Atosa requests that
you register your warranty at
www.atosausa.com
For any service issues, please
contact us at:
Email: service@atosausa.com
or call us Toll Free:
1-855-855-0399
Please clean the filter frequently
DO NOT OVERLOAD
YR140-AP-161 / YR280-AP-161 / YR450-AP-161 / YR800-AP-161
1/ 22
Content
I.
Summary ................................................................................................................................... 2
1. Model ................................................................................................................................ 2
2. Ice production ................................................................................................................... 3
II.
Safety Notices............................................................................................................................ 4
III.
Installation ............................................................................................................................. 5
1. Power supply ..................................................................................................................... 5
2. Construction ...................................................................................................................... 6
3. Accessories ........................................................................................................................ 7
4. Ice bin installation ............................................................................................................. 7
5. Ice machine head installation 7...........................................................................................
6. Obstruction panel installation（no in the self-contained machine） ........................... 8
7. Connect the water inlet hose and drain hose ................................................................... 8
8. Installation location ........................................................................................................... 9
IV.
Operation ............................................................................................................................ 10
1. Checklist before operation .............................................................................................. 10
2. operation ......................................................................................................................... 10
3. Ice weight per batch ........................................................................................................ 11
V.
Maintenance ........................................................................................................................... 12
Clean and sanitize ...........................................................................................................................12
Condenser air- filter wash........................................................................................................ 15
VI.
Service ................................................................................................................................. 16
1. Diagram ........................................................................................................................... 17
2. Safety protection ............................................................................................................. 17
3. LED indication .................................................................................................................. 17
4. Failures analysis ............................................................................................................... 18
5. Customer Support ........................................................................................................... 19
6. Waste disposal ................................................................................................................20
7. Commercial Ice Machine Warranty ................................................................................. 20
2/ 22
I.
Summary
The following data are for reference only
1.
1.
1.
1.1.
Model
Model
Model
ModelModel
Model
YR140- - AP 161
YR280- - AP 161
YR450- - AP 161
YR800- - AP 261
Cooling style
Air
Air
Air
Air
Power supply
110 120V/ -
60Hz
110 120V/ -
60Hz
110 120V -
/60Hz
220 240V -
/60Hz
Power(W)
363
704
9 65
1700
Max Ice
production(IBS/24hr)
140lb
28 0lb
45 0lb
800lb
Dimension(mm)
601*725*981
601*725*981
765 610 57* *5
765 610 801* *
Weight(kg)
65
70
57
90
Refrigerant
R290/90g
R290/90g
R290/150g
R404a/440g
Using temp. range
2 ～43℃
2 ～43℃
2 ～43℃
2 ～43℃
Water temp. range
1 32 ～ ℃
1 32 ～ ℃
1 32 ～ ℃
1 32 ～ ℃
Water pressure range
15 90Psi～
15 90～ Psi
15 90～ Psi
15 90～ Psi
Power range
+10%/-15%
+10%/-15%
+10%/-15%
+10%/-15%
Product Specifications
