Service and Troubleshooting
Package Terminal Air Conditioner / Heat Pump
Standard and Remote Applications with LED Controlboard
R32 and R-410A
© 2019-2023 Daikin Comfort Technologies Manufacturing, L.P.
This manual is to be used by qualied, professionally
trained HVAC technicians only. Goodman does not assume
any responsibility for property damage or personal injury
due to improper service procedures or services performed
by an unqualied person.
RS4200007r1
March 2023
TABLE OF CONTENTS
IMPORTANT INFORMATION ..........................................2
PRODUCT IDENTIFICATION ..........................................3
SYSTEM OPERATION ...................................................12
SCHEDULED MAINTENANCE ......................................30
SERVICING .....................................................................33
CHECKING VOLTAGE ................................................43
CHECKING THERMOSTAT AND WIRING ................ 43
HEATER ASSEMBLY ..................................................44
DRAIN PAN VALVE
(HEAT PUMP MODELS ONLY) ..................................45
CAPACITOR CHECK ..................................................45
CHECKING FAN AND MOTOR
BLOWER WINDINGS..................................................46
COMPRESSOR WINDINGS .......................................47
OVERLOAD .................................................................48
CHECKING COMPRESSOR EFFICIENCY ..............48
FILTER DRIER REPLACEMENT ...............................48
REVERSING VALVE ...................................................49
ACCESSORIES ..............................................................55
WIRING DIAGRAMS ......................................................68
