SPC-L500S / SB
SPC-L350S / SB
In Cabin Speaker Surface Mount
Installation Manual / Einbauanleitung
SPC-L500/350S
EN The In-Cabin speakers requires an additional
subwoofer.
Our recommendation is the Alpine SWC-D84L.
GE Die In-Cabin Lautsprecher benötigen einen
zusätzlichen Subwoofer.
Unsere Empfehlung ist der Alpine SWC-D84L.
SWC-D84L
EN The In-Cabin speakers can be installed horizontally or even vertically.
GE Die In-Cabin Lautsprecher können sowohl horizontal wie auch
vertikal installiert werden.
1. In-Cabin Speaker/ In-Cabin Lautsprecher
2. Speaker grill/ Laut
3. Plasc mounng b
4. Screws/ Schraube
5. Harness/ Anschlus
Parts list / Teileliste / Liste des pièces
5
•PH2 Screwdriver /
•Drilling machine w
Bohrmaschine mit 2mm Bohrer
2mm
SPC-L500/350S
1
2
EN Measure and mark the
fixiation position, pre drill
2mm holes and fix the two
plastic brackets with the
attached screws as shown.
GE Bohren Sie 2mm Löcher vor
und befestigen Sie die beiden
Kunststoffhalter mit den
beiliegenden Schrauben
wie abgebildet.
Zuvor bemessen und
markieren Sie die genaue
Position des Lautsprechers
sowie der Halterungen.
SPC-L350:
20cm
EN Insert the loos terminal into
the connector. >Into P3 for
an active system setup and
into P1 for an passive
sytem setup by using the
integrated HP-capacitor.
GE Stecken Sie den losen
Kontakt in das Stecker-
gehäuse. >In P3 bei einer
aktiven Systemkonfiguration
u. in P1 bei einer passiven
wo der Lautspr. über einen
integrierten HP-Konden-
sator angesteuert wird.
>INPUT SPEAKER >
35cm
SPC-L500/350S
W
A
L
L
-
C
O
R
N
E
R
3cm
3cm
P1: HP-capacitor>
Acve: P3
Passive: P1
