Page 1/34
eMH1
Wallbox
Instruction Manual
with charging socket
VERSION: EMH1-5X2-2017-01-10
ARTICLE NO.: 0301502
ii
Contact
Manufacturer
ABL Sursum
Bayerische Elektrozubehör GmbH & Co. KG
Albert-Büttner-Straße 11
91207 Lauf / Pegnitz
Germany
Phone +49(0)9123 188-0
Fax +49(0)9123 188-188
Web www.abl.de
Email info@abl.de
Support Phone +49(0)9123 188-600
Email emobility.support@abl.de
iii
Contents
Contact . . . . . . . . . . . . . . . . . . . . . . ii
Safety and Operating Notices . . . . . . . . . . . . . . . . . . 1
Safety Notices in this Manual . . . . . . . . . . . . . 1
Safety notices on the device . . . . . . . . . . . . .1
General safety information . . . . . . . . . . . . . .2
Operating instructions / Maintenance . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product description . . . . . . . . . . . . . . . . . 5
Identifying your product variant . . . . . . . . . . . .6
Package contents and unpacking . . . . . . . . . . .7
Available accessories . . . . . . . . . . . . . . . . 7
Installation and power supply connection . . . . . . . . . . . 9
Prerequisites for the mounting site and installation . . . .9
Preparation and mechanical installation . . . . . . . 10
Electrical installation of your Wallbox . . . . . . . . 11
Taking into operation and charging procedure . . . . . . . . 14
Safety information for taking the Wallbox into
operation . . . . . . . . . . . . . . . . . . . . 15
Normal operation . . . . . . . . . . . . . . . . . 15
Charging procedure . . . . . . . . . . . . . . . . 16
Resolving errors . . . . . . . . . . . . . . . . . . . . . . . . 17
Operating states . . . . . . . . . . . . . . . . . 17
Error messages during operation with the vehicle . . . 18
