Page 1/48
VIZIO P50 HDM User Guide
Version - 5/24/2005 1
www.vizioce.com
Table of Contents
Chapter 1 - Introduction ................................................................................................................................2
1.1 - Before Use ......................................................................................................................................... 2
1.2 – Specifications .................................................................................................................................... 2
1.3 - Opening the Package......................................................................................................................... 3
1.4 - Installation.......................................................................................................................................... 3
1.4.1 - Image Sticking............................................................................................................................ 3
1.5 - Important Safety Guidelines............................................................................................................... 4
1.6 - Package Contents.............................................................................................................................. 6
1.7 - Front Panel Controls .......................................................................................................................... 7
1.8 - Side Panel Controls ........................................................................................................................... 7
1.9 - Rear Panel Connections .................................................................................................................... 8
1.10 - VIZIO Universal Remote Control...................................................................................................... 9
1.10.1 - Key Remote Control Functions................................................................................................. 9
1.10.1 - Key Remote Control Functions................................................................................................10
1.10.2 - Insertion of Batteries in the Remote Control............................................................................12
1.10.3 - Remote Control Range............................................................................................................12
1.10.4 - Precautions for the VIZIO Universal Remote Control ..............................................................12
Chapter 2 - Connecting Components.........................................................................................................13
2.1 - Which Video Connection Should I Use? ...........................................................................................13
2.2 - Connecting Your DVD Player............................................................................................................14
2.2.1 - Using HDMI™ (Digital HD) ........................................................................................................14
2.2.2 - Using Component (Analog HD) Video.......................................................................................15
2.2.3 - Using S-Video (AV) ...................................................................................................................16
2.2.4 - Using Composite (AV) Video.....................................................................................................17
2.3 - Connecting Your HDTV Set-Top Box................................................................................................18
2.3.1 - Using HDMI™ (Digital HD) ........................................................................................................18
2.3.2 - Using RGB Video ......................................................................................................................19
2.4 - Connecting Your VCR or Video Camera...........................................................................................19
2.5 - Connecting External Amplified Speakers or Amplifier .......................................................................20
2.6 - Connecting a Computer ....................................................................................................................20
Chapter 3 - Getting Started .........................................................................................................................21
3.1 - Turning your Plas On and ma Monitor Off..........................................................................................21
3.2 - Watching a TV Program....................................................................................................................21
3.3 - Adjusting Basic Plasma Monitor Settings..........................................................................................22
3.4 - Preparing the Plasma for Wall Mounting...........................................................................................23
3.5 - Using the On-Screen Display (OSD).................................................................................................24
3.5.1 - Menu Operations.......................................................................................................................24
3.5.2 - OSD Menus and Options ..........................................................................................................25
3.5.3 - Using the Parental Controls ......................................................................................................29
3.5.4 – Setting a Password...................................................................................................................30
3.6 - Understanding Viewing Features ......................................................................................................31
3.7 - Remote Control Operation ................................................................................................................33
3.7.1 - Programming the VIZIO Universal Remote Control...................................................................33
3.7.2 - Searching for Component Codes ..............................................................................................35
3.7.3 - Reassigning Component Buttons ..............................................................................................35
3.7.4 - Changing Volume Lock .............................................................................................................35
3.7.5 – Using a Cable Box or Satellite Box Remote .............................................................................36
Chapter 4 - Maintenance and Troubleshooting.........................................................................................37
4.1 - Maintenance .....................................................................................................................................37
4.2 - Troubleshooting Guide......................................................................................................................37
4.3 - Telephone & Technical Support........................................................................................................39
4.4 - Compliance .......................................................................................................................................40
4.5 - FCC Class B Radio Frequency Interference Statement....................................................................40
Appendix A: Limited Product Warranty .....................................................................................................41
Appendix B: Component Program Codes .................................................................................................42
Appendix C: Glossary - Standard Definitions ...........................................................................................46
VIZIO P50 HDM User Guide
Version - 5/24/2005 2
www.vizioce.com
Chapter 1 - Introduction
1.1 - Before Use
Congratulations on your VIZIO P50 HDM 50” Plasma monitor purchase. Thank you for your
support of VIZIO and its Plasma display product line. The P50 HDM is a precise electronic
product and you should read the following instructions carefully to maximize the performance of
the product. It has passed the Class-B EMC test and CSA safety certifications and you can be
assured of the highest quality display with the utmost reliability. After you have finished reading
the instructions, put them away in a safe place for future reference.
1.2 – Specifications
Product P50 HDM
Panel: 50" Diagonal, 16:9 Aspect Ratio
Resolution: 1366 x 768 pixels
Pixel (Dot) Pitch: 0.81 (H) mm x .81 mm (V)
Display Compatibility: HDTV (720p)
Signal Compatibility: 480i (SDTV), 480P (EDTV), 720P (HDTV), 1080i (HDTV)
Color: 1 Billion
Brightness: 1000 cd/m2 (typical)
Contrast: 10,000:1 (typical)
Viewing Angle: >170° (horizontal and vertical)
Inputs:
2x Composite Video plus Stereo Audio, 2x S-Video plus Stereo Audio, 2x Component
YPbPr plus Stereo Audio, 1x Analog RGB plus Stereo Audio (shared with Digital Video), 2x
Digital Video (HDMI™**) with HDCP plus Stereo Audio (RCA)
Outputs: 1x Audio, 1x Headphone (Stereo Mini-jack)
Features:
Single Scan Technology for Higher Contrast, Reduced Solarisation and Reduced False
Contouring, and , PIP, POP, CC, V-Chip, 3D Comb Filter, Zoom, Freeze, DCDi® by
Faroudja*** Motion Adaptive De-Interlace, 3-D Noise Reduction, Sharpness Improvement,
Non-linear Chroma Enhancement, Closed Color Suppression, Non-Linear Scaling,
Adaptive Contrast and Color, NTSC Video decoding via Video (CVBS, S-Video or
Component YCbCr), Progressive Scan Video via Component YPbPr, VGA or HDMI™,
HDTV via Component YPbPr, VGA or HDMI™ (Set Top Box required), Computer 640 x
480, 800 x 600, 1024 x 768, 1280 x 1024 via VGA or HDMI™, SRS TruSurround XT****
Sound enhancement.
Speakers: Built-in 10W x 2
Power Input: IEC Connector for direct power line connection
Voltage Range: 100 ~ 240Vac at 50/60 Hz
Power consumption: 550W Max (490W average)
Dimensions: 48.8” x 34.3” x 12.2” (1241 x 871 x 310 mm) w/stand, 48.8” x 33.5” x 3.89” (1241 x 850 x
99 mm) w/o stand
Net Weight: 122 lbs (55.2 kgs) w/stand, and 110 lbs (49.7 kgs) w/o stand
Gross Weight: 144 lbs (65.2 kgs)
Certifications: CSA, FCC Class B
*Product specifications may change without notice or obligation. ** HDMI, the HDMI logo and High-Definition Multimedia
interface are trademarks or registered trademarks of HDMI™ Licensing LLC.
***Registered trademark of Genesis Microchip Inc.
TruSurround XT, SRS and symbol are trademarks of SRS Labs, Inc.
TruSurround XT technology is incorporated under license from SRS Labs, Inc.
Note: In some countries or regions, the shape of the power plug and power outlet may
sometimes differ from that shown in the explanatory drawings. However, the method of
connecting and operating the unit is the same.
