Page 1/44

PA10 DSP, PA12 DSP,

PA15 DSP

active speaker

user manual

Musikhaus Thomann

Thomann GmbH

Hans-Thomann-Straße 1

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

E-mail: info@thomann.de

Internet: www.thomann.de

11.04.2019, ID: 415599, 441076, 441079 (V4)

Table of contents

1 General information 4.................................................................................................................................

1.1 Further information........................................................................................................................... 5

1.2 Notational conventions.................................................................................................................... 6

1.3 Symbols and signal words............................................................................................................... 6

2 Safety instructions 9.....................................................................................................................................

3 Features 15.......................................................................................................................................................

4 Installation 16..................................................................................................................................................

4.1 Tips on handling speakers............................................................................................................ 18

5 Connections and controls 19...................................................................................................................

6 Operating 22....................................................................................................................................................

7 Technical 24specications.......................................................................................................................

8 Plug and connection assignment 37....................................................................................................

9 Protecting the environment 40..............................................................................................................

Table of contents

PA10 DSP, PA12 DSP, PA15 DSP
