Page 1/24

Instruction Manual

Manuale di istruzioni

ﬁn

Gebruiksaanwijzing

Notice d'Utilisation

Bruksanvisning

Brugsvejledning

Bedienungsanleitung

Käyttöohje

Bruksanvisning

ﻡﺩﺧﺗﺳﻣﻟﺍ ﻝﻳﻟﺩ

Instrukcja u

ytkowania

Посібник користувача

N64EU3

Please read this manual before using the product!

Dear Customer,

We'd like you to make the best use of our product, which has been manufactured in modern facilities

with care and meticulous quality controls.

Thus, we advice you to read the entire user manual before you use the product. In case the product

changes hands, do not forget to hand the guide to its new owner along with the product.

This guide will help you use the product quickly and safely.

• Please read the user guide carefully before installing and operating the product.

• Always observe the applicable safety instructions.

• Keep the user guide within easy reach for future use.

• Please read any other documents provided with the product.

Keep in mind that this user guide may apply to several product models. The guide clearly indicates any

variations of different models.

CImportant information and useful

tips.

ARisk of life and property.

BRisk of electric shock.

The product’s packaging is made of

recyclable materials, in accordance

with the National Environment

Legislation.

SUPPLIER’S NAME MODEL IDENTIFIER (*)

INFORMATION

.The model information as stored in the product data base

can be reached by entering following website and searching

for your model identiﬁer (*) found on energy label.

https://eprel.ec.europa.eu/

2 / 23 EN Refrigerator / User Manual

1- Safety Instructions 3

31.1 Intended Use . . . . . . . . . . . . . . . . . . . .

1.2 - Safety for children, vulnerable persons

and pets . . . . . . . . . . . . . . . . . . . . . . . . . .3

41.3 - Electrical safety . . . . . . . . . . . . . . . . .

1.4 - Transportation safety . . . . . . . . . . . . .4

41.5 - Installation safety. . . . . . . . . . . . . . . .

51.6- Operational safety. . . . . . . . . . . . . . . .

1.7- Maintenance and cleaning safety . . . .6

1.8- Lighting . . . . . . . . . . . . . . . . . . . . . . .6

1.9 Compliance with the WEEE Directive and

Disposing of the Waste Product . . . . . . . . .6

1.10 Compliance with RoHS Directive . . . . . .7

1.11 Package information. . . . . . . . . . . . . . .7

1.12 Service . . . . . . . . . . . . . . . . . . . . . . . .7

2 8Your Refrigerator

3 9Installation

3.1 Appropriate location for installation . . . . . . . .9

3.2 Installing the plastic wedges . . . . . . . . . . . . .9

3.3 *Adjusting the feet . . . . . . . . . . . . . . . . . . .10

3.4 Electric connection . . . . . . . . . . . . . . . . . . .11

4 Preparation 12

4.1 Things to be done for saving energy . . . . .12

4.2 Recommendations about the fresh food

compartment. . . . . . . . . . . . . . . . . . . . . .12

4.3 Initial use. . . . . . . . . . . . . . . . . . . . . . . . .13

4.4 Hints and Tips . . . . . . . . . . . . . . . . . . . . . .13

5 Operating the product 14

5.1 Indicator panel. . . . . . . . . . . . . . . . . . . . .14

5.2 Freezing fresh food. . . . . . . . . . . . . . . . . . .16

5.3 Recommendations for preserving the frozen

food . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

5.4 Deep-freeze information . . . . . . . . . . . . . . .16

5.5 Placing the food . . . . . . . . . . . . . . . . . . . . .17

5.6 Door open warning. . . . . . . . . . . . . . . . . . .17

5.7 Crisper. . . . . . . . . . . . . . . . . . . . . . . . . . . .17

5.8 Humidity-controlled crisper . . . . . . . . . . . . .17

5.9 Egg tray . . . . . . . . . . . . . . . . . . . . . . . . . . .18

5.10 Movable Middle Section . . . . . . . . . . . . . .18

5.11 Blue light . . . . . . . . . . . . . . . . . . . . . . . . .18

5.12 Odour filter. . . . . . . . . . . . . . . . . . . . . . . .18

5.13 Making ice . . . . . . . . . . . . . . . . . . . . . . . .18

6. Maintenance and cleaning 19

6.1 Avoiding bad odours . . . . . . . . . . . . . . . . . .19

6.2 Protecting the plastic surfaces . . . . . . . . . .19

7. Troubleshooting 20

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following data available: Model,

Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

VISIT OUR WEBSITE TO:

Get usage advice, brochures, trouble shooter, service and repair information:

www.smeg.com/services/customer-service

3/ 23 EN Refrigerator / User Manual

• This section contains safety instructions that

will help get protected against risks of personal

injury or property damage.

• Our company shall not be responsible

for damages that may arise when these

instructions are not followed.

Installation and repair procedures

must always be performed by the manufacturer,

authorised service agent or a qualified person

specified by the importer.

Only use original parts and accessories.

Original spare parts will be provided for

10 years, following the product purchasing date.

Do not repair or replace any part of the

product unless specified expressly in the user

manual.

Do not make any technical modifications

to the product.

1.1 Intended Use

• This product is not suitable for commercial use

and it must not be used out of its intended use.

This product is designed to be used in houses and

indoor places.

For example:

- Personnel kitchens in stores, offices and

other working environments,

- Farm houses,

- Areas used by customers at hotels, motels

and other types of accommodation,

- Bed&breakfast type hotels, boardinghouses,

- Catering and similar non-retail applications.

This product should not be used outdoors with or

without a tent above it such as boats, balconies or

terraces. Do not expose the product to rain, snow,

sun or wind.

There is the risk of fire!

1.2 - Safety for children,

vulnerable persons and pets

• This product can be used by children at and

above 8 years old and by persons with limited

physical, sensory or mental capabilities or who

lack experience and knowledge provided that

they are supervised or trained on the safe use

of the product and the risks it brings out.

• Children aged from 3 to 8 years are allowed to

load and unload refrigerating products.

• Electrical products are dangerous for children

and pets. Children and pets must not play

with, climb or enter the product.

• Cleaning and user maintenance should not

be performed by children unless they are

supervised by someone.

• Keep packaging materials away from children.

There is the risk of injury and suffocation!

• Before disposing of the old or obsolete

product:

Unplug the product by gripping from the plug.

Cut the power cable and remove it from the

appliance together with its plug

Do not remove the shelves or drawers so that it is

harder for children to enter the product.

Remove the doors.

Keep the product in a way that it will not tip over.

Do not allow children play with the old product.

• Never throw the product into fire for disposal.

There is the risk of explosion!

• If there is a lock on the door of the product,

the key should be kept out of the reach of

children.

1- Safety Instructions

4 / 23 EN Refrigerator / User Manual

Important instructions regarding safety and environment

1.3 - Electrical safety

• The product must be unplugged during

installation, maintenance, cleaning, repairing and

moving procedures.

• If the power cable is damaged, it must be

replaced by a qualified person specified by

the manufacturer, authorised service agent or

importer in order to avoid potential dangers.

• Do not squeeze the power cable under or behind

the product. Do not place heavy objects on the

power cable. Power cable must not be bent

excessively, pinched or get in contact with any

heat source.

• Do not use extension cords, multi-sockets or

adapters to operate the product.

• Portable multi-sockets or portable power sources

can overheat and cause fire. Therefore, do

not keep any multi-sockets behind or near the

product.

• Plug must be easily accessible. If this is not

possible, the electrical installation to which the

product is connected must contain a device

(such as a fuse, switch, circuit breaker, etc.)

which conforms to the electrical regulations and

disconnects all poles from the grid.

• Do not touch the power plug with wet hands.

• Remove the plug from the socket by gripping the

plug and not the cable.

1.4 - Transportation safety

• Product is heavy; do not move it alone.

• Do not hold its door when moving the product.

• Pay attention not to damage the cooling system

or the piping during transportation. If the piping is

damaged, do not operate the product and call the

authorised service agent.

1.5 - Installation safety

• Call the authorised service agent for installation of

the product. To make the product ready for use,

check the information in the user manual to make

sure that the electricity and water installations are

suitable. If they are not, call a qualified electrician

and plumber to have the necessary arrangements

made. Otherwise, there is the risk of electric

shock, fire, problems with the product, or injury!

• Prior to installation, check if the product has

any defects on it. If the product is damaged, do

not have it installed.

• Place the product on a clean, flat and solid

surface and balance it with adjustable feet.

Otherwise, the product may tip over and cause

injuries.

• The installation location must be dry and

well ventilated. Do not place carpets, rugs or

similar covers under the product. Insufficient

ventilation causes the risk of fire!

• Do not cover or block the ventilation openings.

Otherwise, power consumption increases and

your product may get damaged.

• Product must not be connected to supply

systems such as solar power supplies.

Otherwise, your product may get damaged due

to sudden voltage changes!

• The more refrigerant a refrigerator contains,

the larger the installation location must be. If

the installation location is too small, flammable

refrigerant and air mixture will accumulate in

cases of refrigerant leakage in cooling system.

The required space for each 8 gr of refrigerant

is 1 m minimum. The amount of refrigerant in ³

your product is indicated on the Type Label.

• Product must not be installed in places

exposed to direct sunlight and it must be

kept away from heat sources such as hobs,

radiators, etc.

If it is inevitable to install the product close to

a heat source, a suitable insulation plate must

be used in between and the following minimum

distances must be kept to the heat source:

- Minimum 30 cm away from heat sources

such as hobs, ovens, heater units or stoves,

- Minimum 5 cm away from electric ovens.

• Protection class of your product is Type I.

Plug the product in a grounded socket that

conforms the voltage, current and frequency

values stated on the type label of the product.

The socket must be equipped with a 10 A – 16

A circuit breaker. Our company shall not be

liable for any damages that will arise when

the product is used without grounding and

electrical connection in accordance with the

local and national regulations.

5/ 23 EN Refrigerator / User Manual

Important instructions regarding safety and environment

• Product must not be plugged in during

installation. Otherwise, there is the risk of

electric shock and injury!

• Do not plug the product in sockets that are

loose, dislocated, broken, dirty, greasy or bear

the risk of getting in contact with water.

• Route the power cable and hoses (if any) of the

product in a way that they do not cause risk of

tripping over.

• Exposing the live parts or power cable to

humidity may cause short circuit. Therefore,

do not install the product in places such as

garages or laundry rooms where humidity is

high or water may splash. If the refrigerator

gets wet with water, unplug it and call the

authorised service agent.

• Never connect your refrigerator to energy

saving devices. Such systems are harmful to

your product.

1.6- Operational safety

• Never use chemical solvents on the product.

There is the risk of explosion!

• If the product malfunctions, unplug it and do

not operate until it is repaired by the authorised

service agent. There is the risk of electric

shock!

• Do not place flame sources (lit candles,

cigarettes, etc.) on or close to the product.

• Do not climb on the product. There is the risk

of falling and getting injured!

• Do not damage the pipes of the cooling

system with sharp or penetrating objects.

The refrigerant that might come out when the

refrigerant pipes, pipe extensions or surface

coatings are punctured causes skin irritations

and eye injuries.

• Unless recommended by the manufacturer, do

not place or use electrical devices inside the

refrigerator/deep freezer.

• Be careful not to trap your hands or any other

part of your body in the moving parts inside the

refrigerator. Pay attention not to squeeze your

fingers between the door and the refrigerator.

Be careful when opening and closing the door

particularly if there are children around.

• Never eat ice cream, ice cubes or frozen food

right after removing them from the refrigerator.

There is the risk of frostbite!

• When your hands are wet, do not touch the

inner walls or metal parts of the freezer or

the food stored therein. There is the risk of

frostbite!

• Do not place tins or bottles that contain

carbonated drinks or freezable liquids in the

freezer compartment. Tins and bottles may

burst. There is the risk of injury and material

damage!

• Do not place or use flammable sprays,

flammable materials, dry ice, chemical

substances or similar heat-sensitive materials

near the refrigerator. There is the risk of fire and

explosion!

• Do not store explosive materials that contain

flammable materials, such as aerosol cans, in

your product.

• Do not place containers filled with liquid onto

the product. Splashing water on an electrical

part may cause electric shock or the risk of fire.

• This product is not intended for storing

medicines, blood plasma, laboratory

preparations or similar medical substances and

products subject to Medical Products Directive.

• Using the product against its intended purpose

may cause the products stored inside it to

deteriorate or spoil.

• If your refrigerator is equipped with blue light,

do not look at this light with optical tools. Do

not stare at UV LED lamp directly for a long

time. Ultraviolet light may cause eye strain.

• Do not overload the product. Objects in the

refrigerator may fall down when the door is

opened, causing injury or damage. Similar

problems may arise if any object is placed onto

the product.

• To avoid injuries, make sure that you have

cleaned all the ice and water that may have

fallen or splashed on the floor.

• Change the position of the shelves/bottle

holders on the door of your refrigerator only

when they are empty. There is the risk of injury!

• Do not place objects that can fall down/tip over

onto the product. Such objects may fall down

when the door is opened and cause injuries

and/or material damage.

6 / 23 EN Refrigerator / User Manual

Important instructions regarding safety and environment

• Do not hit or exert excessive force on glass

surfaces. Broken glass may cause injuries and/or

material damage.

• Cooling system of your product contains R600a

refrigerant: Type of the refrigerant used in the

product is indicated on the type label. This

refrigerant is flammable. Therefore, pay attention

not to damage the cooling system or the piping

while the product is in use. If the piping is

damaged:

- Do not touch the product or the power cable,

- Keep away potential sources of fire that may

cause the product to catch fire.

- Ventilate the area where the product is located.

Do not use fans.

- Call the authorised service agent.

• If the product is damaged and you see refrigerant

leak, please stay away from the refrigerant.

Refrigerant may cause frostbite in case of skin

contact.

For products with a Water Dispenser/

Ice Machine

• Use only potable water. Do not fill the

water tank with any liquids -such as

fruit juice, milk, carbonated beverages

or alcoholic drinks- that are not suitable

for use in the water dispenser.

• There is the risk for health and safety!

• Do not allow children play with the

water dispenser or ice machine

(Icematic) in order to prevent accidents

or injuries.

• Do not insert your fingers or other

objects into the water dispenser hole,

water channel or ice machine container.

There is the risk of injury or material

damage!

1.7- Maintenance and

cleaning safety

• Do not pull from the door handle if you need

to move the product for cleaning purposes.

Handle may break and cause injuries if you exert

excessive force on it.

• Do not spray or pour water on or inside the

product for cleaning purposes. There is the risk

of fire and electric shock!

• Do not use sharp or abrasive tools when

cleaning the product. Do not use household

cleaning products, detergent, gas, gasoline,

thinner, alcohol, varnish etc.

• Only use cleaning and maintenance products

inside the product that are not harmful for

food.

• Never use steam or steam assisted cleaners to

clean or defrost the product. Steam gets into

contact with the live parts in your refrigerator,

causing short circuit or electric shock!

• Make sure that no water enters the electronic

circuits or lighting elements of the product.

• Use a clean and dry cloth to wipe the foreign

materials or dust on the pins of the plug. Do

not use a wet or damp cloth to clean the plug.

There is the risk of fire and electric shock!

1.8- Lighting

• Call the authorised service when it is required

to replace the LED/bulb used for lighting.

1.9 Compliance with the WEEE

Directive and Disposing

of the Waste Product

This product complies with EU WEEE Directive

(2012/19/EU). This product bears a classification

symbol for waste electrical and electronic equip-

ment (WEEE).

This symbol indicates that this product

shall not be disposed with other house-

hold wastes at the end of its service life.

Used device must be returned to offical

collection point for recycling of electrical

and electronic devices. To find these collection sys-

tems please contact to your local authorities or re-

tailer where the product was puchased. Each

household performs important role in recovering

and recycling of old appliance. Appropriate disposal

of used appliance helps prevent potential negative

consequences for the environment and human

health.

7/ 23 EN Refrigerator / User Manual

Important instructions regarding safety and environment

1.10 Compliance with

RoHS Directive

The product you have purchased complies with EU

RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the

Directive.

1.11 Package information

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations. Do not dis-

pose of the packaging materials together with the

domestic or other wastes. Take them to the pack-

aging material collection points designated by the

local authorities.

1.12 Service

• To repair the appliance contact the Authorised

Service Centre. Use original spare parts only.

• Please note that self-repair or nonprofessional

repair can have safety consequences and might

void the guarantee.

• The following spare parts will be available for 7

years after the model has been discontinued:

thermostats, temperature sensors, printed

circuit boards, light sources, door handles, door

hinges, trays and baskets. Please note that

some of these spare parts are only available

to professional repairers, and that not all spare

parts are relevant for all models.

• Door gaskets will be available for 10 years after

the model has been discontinued.

8 / 23 EN Refrigerator / User Manual

CFigures in this user manual are schematic and may not match the product exactly. If the subject parts

are not included in the product you have purchased, then those parts are valid for other models.

2 Your Refrigerator

*11

1- Control and indicator panel

2- Butter & Cheese section

3- 70 mm moving door shelf

4- Fridge compartment glass shelf

5- Fridge compartment crisper

6- Gallon door shelf

7- Dairy compartment

8- Icebox drawer

9- Freezer compartment glass shelf/cooler

10- Freezer compartment drawers

11- Water tank

* OPTIONAL

9/ 23 EN Refrigerator / User Manual

3.1 Appropriate location

for installation

Contact an Authorized Service for the installation

of the product. In order to prepare the product

for use, refer the information in the user manual

and ensure that electrical installation and water

installation are appropriate. If not, call a qualified

electrician and technician to have any necessary

arrangements carried out.

BWARNING: Manufacturer shall not

be held liable for damages that may

arise from procedures carried out by

unauthorized persons.

BWARNING: Product must not be plugged

in during installation. Otherwise, there is

the risk of death or serious injury!

WARNING: : If the door clearance of the

room where the product shall be placed is

so tight to prevent passing of the product,

remove the door of the room and pass the

product through the door by turning it to

its side; if this does not work, contact the

authorized service.

• Place the product on a level floor surface to

prevent jolts.

• Install the product at least 30 cm away from

heat sources such as hobs, heater cores and

stoves and at least 5 cm away from electrical

ovens.

• Product must not be subjected to direct sun light

and kept in humid places.

• Your product requires adequate air circulation to

function efficiently. If the product will be placed

in an niche, remember to leave at least 5 cm

clearance between the product and the ceiling,

rear wall and the side walls.

• If the product will be placed in an niche,

remember to leave at least 5 cm clearance

between the product and the ceiling, rear

wall and the side walls. Check if the rear wall

clearance protection component is present at

its location (if provided with the product). If the

component is not available, or if it is lost or

3 Installation

fallen, position the product so that at least 5 cm

clearance shall be left between the rear surface

of the product and the wall of the room. The

clearance at the rear is important for efficient

operation of the product.

• Do not install the product in places where the

temperature falls below -5°C.

3.2 Installing the plastic wedges

Plastic wedges supplied with the product are

used to create the distance for the air circulation

between the product and the rear wall.

To install the wedges, remove the screws on the

product and use the screws supplied together with the

wedges.

Insert the 2 plastic wedges onto the rear ventilation

cover as illustrated in the figure.

10 / 23 EN Refrigerator / User Manual

Installation

3.3 *Adjusting the feet

If the product stands unbalanced after installation,

adjust the feet on the front by rotating them to the

right or left.

*If your product does not have a wine

compartment or is not a glass door, your product

does not have adjustable stands, the product has

fixed stands.

To adjust the doors vertically,

Loosen the fixing nut located at the bottom.

Rotate the adjusting nut according to the position

of the door (clockwise/counter-clockwise).

Tighten the fixing nut in order to fix the position.

To adjust the doors horizontally,

Loosen the fixing nut located at the top.

Rotate the side adjusting nut according to the

position of the door (clockwise/counter-clockwise).

Tighten the fixing nut which is at the top in order to

fix the position.

adjusting nut

ﬁxing nut

adjusting nut

11/ 23 EN Refrigerator / User Manual

Installation

3.4 Electric connection

WARNING: Do not make connections via

extension cables or multi-plugs.

BWARNING: Damaged power cable must

be replaced by the Authorized Service

Agent.

CIf two coolers are to be installed side

by side, there should be at least 4 cm

distance between them.

• Our company shall not be liable for any

damages that will arise when the product

is used without grounding and electrical

connection in accordance with the national

regulations.

• Power cable plug must be within easy reach

after installation.

• Do not extension cords or cordless multiple

outlets between your product and the wall

outlet.

-Upper hinge group is fixed with 3 screws.

-The hinge cover is attached after the sockets are

installed.

- Then the hinge cover is fixed with two screws.

Positioning

This appliance should be installed in a dry, well

ventilated indoor position.

This appliance is intended to be used at ambient

temperature ranging from 10°C to 43°C.

14 / 23 EN Refrigerator / User Manual

5.1 Indicator panel

Touch-control indicator panel allows you to set the temperature and control the other functions related to

the product.Just press the relevant buttons for function settings.

CFigures in this user manual are schematic and may not match the product exactly. If the subject parts

are not included in the product you have purchased, then those parts are valid for other models.

* (in some models)

1-On/Off function

Press the On/Off button for 3 seconds to turn off or

turn on the fridge.

2. Temperature Adjustment Fridge

When pressed decreases the temperature of the

fridge compartment.

3. Temperature Adjustment Freezer

When pressed decreases the temperature of the

frreezer compartment.

4. Temperature Adjustment Joker

When pressed decreases the temperature of the

joker compartment.

5-Quick freeze Indicator

This icon lits when the Quick freeze function is

active.

6. Fridge compartment indicator

When this indicator is active, the temperate of the

fridge compartment is displayed on the temperature

value indicator.Fridge compartment can be set

to 8, 7, 6, 5, 4, 3, 2 or 1°C / 46, 45, 44, 43, 42,

41, 40,39,38,37,36,35,34 or 33 F by pressing °

Temperature Adjustment button (2).

7. Temperature value indicator

Shows the temperature value of the selected

compartment.

8. Fahrenheit indicator

It is a Fahrenheit indicator. When the Fahrenheit

indication is activated, the temperature set values

are shown in Fahrenheit and the relevant icon

turns on.

9. Joker fridge icon

This icon indicates that joker cabin in fridge mode.

Mode can be change by pressing joker set button

(4) 3 seconds.

10. Joker cabin icon

It shows joker cabin icon.

11. Joker freezer icon

This icon indicates that joker cabin in freezer

mode. Mode can be change by pressing joker set

button (4) 3 seconds.

12. Power failure/High temperature / error

warning

This indicator illuminates during power failure, high

temperature failures and error warnings. During

long-term power failures, the highest temperature

value that the freezer compartment reaches will

blink on the digital display. After checking the food

located in the freezer compartment, press the

alarm off button (19) to clear the warning.

13.Setting the Celsius and Fahrenheit

indicator

By pressing 3 seconds to ıce off 18 temperature

unit can be changed between celcius and

fahrenheit .When the relevant temperature type

is selected, the Fahrenheit and Celsius indicator

turns on.

5 Operating the product

1 2 3 45 6

24 *23

*22 21 *20

*9 12 14 1513*1110 1716 *18 19

26 25

16 / 23 EN Refrigerator / User Manual

Operating the product

5.2 Freezing fresh food

• In order to preserve the quality of the food, it

shall be frozen as quickly as possible when it is

placed in the freezer compartment, use the fast

freezing feature for this purpose.

• You may store the food longer in freezer

compartment when you freeze them while they

are fresh.

• Pack the food to be frozen and close the

packing so that it would not allow entrance of

air.

• Ensure that you pack your food before putting

them in the freezer. Use freezer containers,

foils and moisture-proof papers, plastic

bags and other packing materials instead of

traditional packing papers.

• Label each pack of food by adding the date

before freezing. You may distinguish the

freshness of each food pack in this way when

you open your freezer each time. Store the food

frozen before in the front side of compartment

to ensure that they are used first.

• Frozen food must be used immediately after

they are thawed and they should not be re-

frozen.

• Do not freeze too large quantities of food at

one time.

• 24 hours before freezing the fresh food,

activate “Quick Freeze Function”.

• The fresh food packages should be placed in

bottom drawers.

• After placing fresh food packages, activate

“Quick Freeze Function” again.

• When the freezer cabinet is set to quick

function, joker cabinet is also set to quick

function automatically.

5.3 Recommendations for

preserving the frozen food

Compartment shall be set to -18°C at least.

1. Put packages in the freezer as quickly as

possible after purchase without allowing the

to thaw.

2. Check whether the "Use By" and "Best

Before" dates on the packaging are expired or

not before freezing it.

3. Ensure that the package of the food is not

damaged.

5.4 Deep-freeze information

According to IEC 62552 standards, the product

shall freeze at least 4.5 kg of food at 25°C

ambient temperature to -18°C or lower within 24

hours for every 100-litres of freezer volume.

It is possible to preserve the food for a long time

only at -18°C or lower temperatures.

You can keep the freshness of food for many

months (at -18°C or lower temperatures in the

deep freeze).

Foods to be frozen should not be allowed to come

in contact with the previously frozen items to

prevent them from getting thawed partially.

Freezer

Compartment

Setting

Fridge

Compartment

Setting

Remarks

-18°C 4°C This is the normal recommended setting.

-20, -22 or

-24°C 4°C These settings are recommended when the ambient temperature

exceeds 30°C.

Quick Freeze 4°C Use when you wish to freeze your food in a short time. Your product

will return to its previous mode when the process is over.

-18°C or colder 2°C

Use these settings if you think that your fridge compartment is not

cold enough because of the hot ambient conditions or frequent

opening and closing of the door.

17/ 23 EN Refrigerator / User Manual

Operating the product

Boil the vegetables and drain their water in order

to store vegetables for a longer time as frozen.

After draining their water, put them in air-proof

packages and place them inside the freezer. Food

such as bananas, tomatoes, lettuce, celery, boiled

eggs, potatoes are not suitable for freezing. When

these foods are frozen, only their nutritional value

and taste shall be affected negatively. They shall

not be spoiled so that they would create a risk for

human health.

5.5 Placing the food

Freezer

compartment

shelves

Various frozen food such

as meat, fish, ice cream,

vegetables and etc.

Refrigerator

compartment

shelves

Food in pans, covered plates

and closed containers, eggs (in

closed container)

Door shelves

of fridge

compartment

Small and packaged food or

beverage

Crisper Vegetables and fruits

Fresh zone

compartment

Delicatessen (breakfast food,

meat products that shall be

consumed in a short time)

5.6 Door open warning

(This feature is optional)

The door open alert system of your refrigerator

may differ depending on the model.

Version 1;

If the door of the product remains open for a

certain time (between 60 s and 120 s), an audio

warning signal sounds; depending on the product

model, a visual warning signal (light flash) can also

be displayed. If you close the door of the device or

press a button on the screen of the device, if any,

the warning sound will stop.

Version 2;

If the door of the device remains open for a certain

period of time (between 60 s and 120 s), the

door open alert is sounded. The door open alert is

sounded gradually. First, an audible warning starts

to sound. After 4 minutes, if the door is still not

closed, a visual warning (lighting flash) is activated.

The door open alert will be delayed for a certain

period of time (between 60 s and 120 s) when any

key on the product screen, if any, is pressed. Then

the process will start again. When the device door

is closed, the door open alert will be cancelled.

5.7 Crisper

Crisper of the refrigerator is designed specially

to keep the vegetables fresh without loosing their

humidity. For this purpose, cool air circulation is

intensified around the crisper in general. Remove

the door shelves that stand against the crisper

before removing the crisper.

5.8 Humidity-controlled crisper

(This feature is optional)

Humidity rates of fruits and vegetables are kept

under control thanks to the humidity-controlled

crisper and thus the food is ensured to stay fresh

for a longer period.

We recommend that you place leafy vegetables

such as lettuce and spinach and vegetables sensi-

tive to humidity loss as horizontally as possible

when putting them in the crisper; not in a horizon-

tal position on their roots.

While the vegetables are being replaced, their spe-

cific weights should be taken into consideration.

Heavy and hard vegetables must be placed at the

bottom of the crisper and light and soft vegetables

must be on the upper part.

Never leave the vegetables in their plastic bags in

the crisper. If they are left in their plastic bags, this

will cause them to rot in a little while. If you not

prefer the vegetable to get in contact with other

vegetables for hygienic reasons, use perforated

paper or a similar material instead of plastic bags.

Do not place pears, apricots, peaches etc.,

18 / 23 EN Refrigerator / User Manual

Operating the product

especially those fruits that generate large amounts

of ethylene, in the same crisper with other fruits

and vegetables. The ethylene gas emitted by these

fruits cause other fruits to ripen sooner and to rot

in a shorter span of time.

5.9 Egg tray

You can install the egg holder to the desired door

or body shelf.

Never keep the egg holder in the freezer

compartment.

5.10 Movable Middle Section

Movable middle section is intended to prevent

the cold air inside your refrigerator from escaping

outside.

5.11 Blue light

(in some models)

Crisper of the refrigerator are illuminated with a

blue light. Foodstuff stored in the crisper continue

their photosynthesis by means of the wavelength

effect of blue light and thus, preserve their

freshness and increase their vitamin content.

5.12 Odour filter

Odour filter in the air duct of the fridge

compartment prevents build-up of unpleasant

odours in the refrigerator.

5.13 Making ice

(in some models)

Fill the ice container with water and place it into

the freezer compartment. Your ice will be ready

approximately in two hours.

You can remove the ice in the ice container by

removing it from the freezer and twisting it.

1- Sealing is provided when the gaskets on the

door presses on the surface of the movable middle

section while the fridge compartment doors are

closed.

2- Another reason that your refrigerator is

equipped with a movable middle section is that it

increases the net volume of the fridge compart-

ment. Standard middle sections occupy some

non-usable volume in the refrigerator.

3-Movable middle section is closed when the left

door of the fridge compartment is opened.

4-It must not be opened manually. It moves under

the guidance of the plastic part on the body while

the door is closed.

19/ 23 EN Refrigerator / User Manual

6. Maintenance and cleaning

Cleaning your fridge at regular intervals will ex-

tend the service life of the product.

B WARNING:

Unplug the product before cleaning it.

• Never use gasoline, benzene or similar

substances for cleaning purposes.

• Never use any sharp and abrasive tools, soap,

household cleaners, detergent and wax polish

for cleaning.

• For non-No Frost products, water drops and

frosting up to a fingerbreadth occur on the rear

wall of the Fridge compartment. Do not clean it;

never apply oil or similar agents on it.

• Only use slightly damp microfiber cloths to clean

the outer surface of the product. Sponges and

other types of cleaning cloths may scratch the

surface

• Dissolve one teaspoon of bi-carbonate in half

litre of water. Soak a cloth with the solution

and wrung it thoroughly. Wipe the interior of

the refrigerator with this cloth and the dry

thoroughly.

• Make sure that no water enters the lamp

housing and other electrical items.

• If you will not use the refrigerator for a long

period of time, unplug it, remove all food inside,

clean it and leave the door ajar.

• Check regularly that the door gaskets are clean.

If not, clean them.

• To remove door and body shelves, remove all of

its contents.

• Remove the door shelves by pulling them up.

After cleaning, slide them from top to bottom to

install.

• Never use cleaning agents or water that

contain chlorine to clean the outer surfaces and

chromium coated parts of the product. Chlorine

causes corrosion on such metal surfaces.

6.1 Avoiding bad odours

• Materials that may cause odour are not used in

the production of our refrigerators. However, due

to inappropriate food preserving conditions and

not cleaning the inner surface of the refrigerator

as required can bring forth the problem of odour.

Pay attention to following to avoid this problem:

• Keeping the refrigerator clean is important.

Food residuals, stains, etc. can cause odour.

Therefore, clean the refrigerator with bi-

carbonate dissolved in water every few months.

Never use detergents or soap.

• Keep the food in closed containers.

Microorganisms spreading out from uncovered

containers can cause unpleasant odours.

• Never keep the food that have passed best

before dates and spoiled in the refrigerator.

6.2 Protecting the plastic surfaces

Do not put liquid oils or oil-cooked meals in your

refrigerator in unsealed containers as they dam-

age the plastic surfaces of the refrigerator. If oil is

spilled or smeared onto the plastic surfaces, clean

and rinse the relevant part of the surface at once

with warm water.

20 / 23 EN Refrigerator / User Manual

7. Troubleshooting

Check this list before contacting the service.

Doing so will save you time and money. This list

includes frequent complaints that are not related to

faulty workmanship or materials. Certain features

mentioned herein may not apply to your product.

The refrigerator is not working.

• The power plug is not fully settled. >>> Plug it

in to settle completely into the socket.

• The fuse connected to the socket powering the

product or the main fuse is blown. >>> Check

the fuses.

Condensation on the side wall of the cooler

compartment (MULTI ZONE, COOL, CONTROL

and FLEXI ZONE).

• The door is opened too frequently >>>

Take care not to open the product’s door too

frequently.

• The environment is too humid. >>> Do not

install the product in humid environments.

• Foods containing liquids are kept in unsealed

holders. >>> Keep the foods containing liquids

in sealed holders.

• The product’s door is left open. >>> Do not

keep the product’s door open for long periods.

• The thermostat is set to too low temperature.

>>> Set the thermostat to appropriate

temperature.

Compressor is not working.

• In case of sudden power failure or pulling the

power plug off and putting back on, the gas

pressure in the product’s cooling system is

not balanced, which triggers the compressor

thermic safeguard. The product will restart after

approximately 6 minutes. If the product does not

restart after this period, contact the service.

• Defrosting is active. >>> This is normal for

a fully-automatic defrosting product. The

defrosting is carried out periodically.

• The product is not plugged in. >>> Make sure

the power cord is plugged in.

• The temperature setting is incorrect. >>>

Select the appropriate temperature setting.

• The power is out. >>> The product will continue

to operate normally once the power is restored.

The refrigerator’s operating noise is

increasing while in use.

• The product’s operating performance may

vary depending on the ambient temperature

variations. This is normal and not a malfunction.

The refrigerator runs too often or for too

long.

• The new product may be larger than the

previous one. Larger products will run for longer

periods.

• The room temperature may be high. >>> The

product will normally run for long periods in

higher room temperature.

• The product may have been recently plugged

in or a new food item is placed inside. >>>

The product will take longer to reach the set

temperature when recently plugged in or a new

food item is placed inside. This is normal.

• Large quantities of hot food may have been

recently placed into the product. >>> Do not

place hot food into the product.

• The doors were opened frequently or kept open

for long periods. >>> The warm air moving

inside will cause the product to run longer. Do

not open the doors too frequently.

• The freezer or cooler door may be ajar. >>>

Check that the doors are fully closed.

• The product may be set to temperature too low.

>>> Set the temperature to a higher degree

and wait for the product to reach the adjusted

temperature.

• The cooler or freezer door washer may be

dirty, worn out, broken or not properly settled.

>>> Clean or replace the washer. Damaged

/ torn door washer will cause the product to

run for longer periods to preserve the current

temperature.

The freezer temperature is very low, but the

cooler temperature is adequate.

• The freezer compartment temperature is set

to a very low degree. >>> Set the freezer

compartment temperature to a higher degree

and check again.

The cooler temperature is very low, but the

freezer temperature is adequate.

• The cooler compartment temperature is set

to a very low degree. >>> Set the freezer

compartment temperature to a higher degree

and check again.

21/ 23 EN Refrigerator / User Manual

Troubleshooting

The food items kept in cooler compartment

drawers are frozen.

• The cooler compartment temperature is set

to a very low degree. >>> Set the freezer

compartment temperature to a higher degree

and check again.

The temperature in the cooler or the freezer

is too high.

• The cooler compartment temperature is set to

a very high degree. >>> Temperature setting

of the cooler compartment has an effect on the

temperature in the freezer compartment. Wait

until the temperature of relevant parts reach the

sufficient level by changing the temperature of

cooler or freezer compartments.

• The doors were opened frequently or kept open

for long periods. >>> Do not open the doors too

frequently.

• The door may be ajar. >>> Fully close the door.

• The product may have been recently plugged in

or a new food item is placed inside. >>> This is

normal. The product will take longer to reach the

set temperature when recently plugged in or a

new food item is placed inside.

• Large quantities of hot food may have been

recently placed into the product. >>> Do not

place hot food into the product.

Shaking or noise.

• The ground is not level or durable. >>> If the

product is shaking when moved slowly, adjust

the stands to balance the product. Also make

sure the ground is sufficiently durable to bear

the product.

• Any items placed on the product may cause

noise. >>> Remove any items placed on the

product.

The product is making noise of liquid

flowing, spraying etc.

• The product’s operating principles involve liquid

and gas flows. >>> This is normal and not a

malfunction.

There is sound of wind blowing coming from

the product.

• The product uses a fan for the cooling process.

This is normal and not a malfunction.

There is condensation on the product’s

internal walls.

• Hot or humid weather will increase icing and

condensation. This is normal and not a malfunction.

• The doors were opened frequently or kept open for long

periods. >>> Do not open the doors too frequently; if

open, close the door.

• The door may be ajar. >>> Fully close the door.

There is condensation on the product’s exterior or

between the doors.

• The ambient weather may be humid, this is quite normal

in humid weather. >>> The condensation will dissipate

when the humidity is reduced.

The interior smells bad.

• The product is not cleaned regularly. >>> Clean

the interior regularly using sponge, warm water and

carbonated water.

• Certain holders and packaging materials may cause

odour. >>> Use holders and packaging materials

without free of odour.

• The foods were placed in unsealed holders. >>> Keep

the foods in sealed holders. Micro-organisms may

spread out of unsealed food items and cause malodour.

Remove any expired or spoilt foods from the product.

The door is not closing.

• Food packages may be blocking the door. >>> Relocate

any items blocking the doors.

• The product is not standing in full upright position on the

ground. >>> Adjust the stands to balance the product.

• The ground is not level or durable. >>> Make sure

the ground is level and sufficiently durable to bear the

product.

The vegetable bin is jammed.

• The food items may be in contact with the upper section

of the drawer. >>> Reorganize the food items in the

drawer.

If The Surface Of The Product Is Hot.

• High temperatures may be observed between the two

doors, on the side panels and at the rear grill while the

product is operating. This is normal and does not require

service maintenance!Be careful when touching these

areas.

A WARNING:

If the problem persists after following the instructions in

this section, contact your vendor or an Authorised Service.

Do not try to repair the product.

Product Specifications

Brand:	Smeg
Category:	Refrigerator
Model:	FQ60CAO6

Do you need help?

If you need help with Smeg FQ60CAO6, ask a question below and other users will answer you

Your Name*

Your Email*

Write your question here

Refrigerator Smeg User Manuals

Smeg FQ60XPE Manual

22 October 2024

Smeg UKC8173N1E Manual

19 October 2024

19 October 2024

19 October 2024

18 October 2024

18 October 2024

18 October 2024

18 October 2024

18 October 2024

18 October 2024

Refrigerator User Manuals

Latest Refrigerator User Manuals

Bosch KIN85NSE0G Manual

27 October 2024

LG GN-B563YC Manual

27 October 2024

Exquisit KS18-4-H-170D Manual

27 October 2024

Exquisit KS18-V-H-170E Manual

27 October 2024

Exquisit KS18-4-H-170E Manual

27 October 2024

Electrolux ETM3600 Manual

27 October 2024

Electrolux ESE6107 Manual

27 October 2024

Electrolux ETM3900 Manual

27 October 2024

Electrolux ERM4307 Manual

27 October 2024

Electrolux ETM5207 Manual

27 October 2024
