Samsung RL25DATW Manual
Read below 📖 the manual in Italian for Samsung RL25DATW (20 pages) in the Freezer category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users
Page 1/20
MODEL:
RL-24MBSW
RL-24MBSI
SERVICE
SER
SER
SER
SERVICE
VICE
VICE
VICE
MANUAL
MANUAL
MANUAL
MANUAL
MANUAL
CONTENTS
REFRIGERATOR
1. PRECAUTION......................................................................1
2. PRODUCT SPECIFICATION...............................................2
3. STRUCTURE.......................................................................3
4. CIRCULATION OF REFRIGERANT.....................................5
5. SCHEMATIC- DIAGRAM......................................................6
6. SPECIFICATIONS OF MAJOR FUNCTIONAL PARTS........7
7. OPERATING PRINCIPLE OF MAJOR COMPONENTS
AND INSPECTION METHOD..............................................8
8. HOW TO REPLACE MAJOR COMPONENTS...................11
9. TROUBLE -SHOOTING.....................................................13
10. EXPLODED VIEW AND PARTS LIST...............................14
1-1. Safety precautions
1-1. Safety precautions
1-1. Safety precautions
1-1. Safety precautions
1-1. Safety precautions
Only qualified service technicians who are thoroughly familiar with the refrigerating cycle and the
required safety checks should perform service operations in accordance with specified guidelines.
1 -1-1. Prior to servicing, be sure to disconnect the product from its electrical power source by removing the
products eletrical plug from the wall receptacle to preclude the possibility of resultant presonal injury
and / or property damage.
1-1-2. Never attempt to modify or bypass circuit connections in ways not recommended by the manufacturer.
1-1-3. Do not use any extension or double adaptors.
1-1-4. For person safety, this appliance must be properly grounded.
This refrigerator should not be grounded with a telephone line, gas pipe etc.
1 -2-1. In case of article No.1 and starting capacitor ( itself only ) do not supply power in order to check for
eletrical charge and discharge for more than two minutes. When power is supplied for more than two
minutes, the insulation inside the capacitor may be broken. When it is impossible to finish the test
within two minutes, wait for about 30 minutes, and then check again.
1-2-2. When replacing the relay connected to the compressor terminal pin, be sure to pull it off straight and
push it on straight, Swaying of the relay side-to-side or up and down, may cause damage to the
compressor terminal pin and / or the relay.
1-2-3. Wait more than 5 minutes to re-start the refrigerator after you stop it once.
If you plug in the refrigerator immediately after you pull the plug, you may not be able to start it again.
1-2. Servicing precautions
1-2. Servicing precautions
1-2. Servicing precautions
1-2. Servicing precautions
1-2. Servicing precautions
: This is safety-related information on the A/ C power circuits and parts used in the refrigerator.
: This is the information required for repairing the refrigerator.
1
1.PRECAUTION
2
Model RL24MBSW RL24MBSI
Type Two door refrigerator & freezer
Power supply AC 220V~50Hz
Refrigerator
Total
156L
Capacity 211L
Overall
dimensions
(mm)
Width 550
Depth 664
Height 1580
Refrigerant(Sealed volume:g)
HFC-134a(150g)
Temperature control Mechanical(Thermostat)
Insulation material
Door Seal
Polyurethane Foam(141b)
Liner ABS
Magnetic gasket
Acces
sories
Door Storage(Option)
1Guard-Bottle,2Guard-Egg,1Tray Ice,1Tray Egg
FreezerStorage
Ref Storage
2 Assy Tray Upp,1 Assy Tray Low
2 Assy Shelves,1 Assy Tray Veg
Printed Matter Owner's Manual,Label
2.PRODUCT SPECIFICATION
Product Specifications
| Brand: | Samsung |
| Category: | Freezer |
| Model: | RL25DATW |
