Page 1/36
Air conditioner
Installation manual
AC***TN*DKC
࡙Thank you for purchasing this Samsung air conditioner.
࡙Before operating this unit, please read this manual carefully and retain it for future reference.
2English
Contents
Safety Information 3
Installation Procedure 6
Step 1 Checking and preparing accessories 6
Step 2 Choosing the installation location 6
Step 3 Optional: Insulating the body of the indoor unit 11
Step 4 Installing the indoor unit 12
Step 5 Purging inert gas from the indoor unit 13
Step 6 Cutting and flaring the pipes 14
Step 7 Connecting the assembly pipes to the refrigerant pipes 14
Step 8 Performing the gas leak test 15
Step 9 Insulating the refrigerant pipes 15
Step 10 Installing the drain hose and drain pipe 17
Step 11 Performing the drainage test 19
Step 12 Connecting the power and communication cables 20
Step 13 Optional: Extending the power cable 21
Step
14 Setting the indoor unit addresses and the installation options 22
Appendix 34
Troubleshooting 34
3
English
Safety Information
WARNING
࡙Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION
࡙Hazards or unsafe practices that may result in minor
personal injury or property damage.
࡙Carefully follow the precautions listed below because
they are essential to guarantee the safety of the
equipment.
WARNING
࡙Always disconnect the air conditioner from the power
supply before servicing it or accessing its internal
components.
࡙Verify that installation and testing operations are
performed by qualified personnel.
࡙Verify that the air conditioner is not installed in an
easily accessible area.
General information
WARNING
࡙Carefully read the content of this manual before
installing the air conditioner and store the manual in
a safe place in order to be able to use it as reference
after installation.
࡙For maximum safety, installers should always carefully
read the following warnings.
࡙Store the operation and installation manual in a safe
location and remember to hand it over to the new
owner if the air conditioner is sold or transferred.
࡙This manual explains how to install an indoor unit with
a split system with two SAMSUNG units. The use of
other types of units with different control systems may
damage the units and invalidate the warranty. The
manufacturer shall not be responsible for damages
arising from the use of non compliant units.
࡙The manufacturer shall not be responsible for damage
originating from unauthorized changes or the
improper connection of electric and requirements set
forth in the “Operating limits” table, included in the
manual, shall immediately invalidate the warranty.
࡙The air conditioner should be used only for the
applications for which it has been designed: the indoor
unit is not suitable to be installed in areas used for
laundry.
࡙Do not use the units if damaged. If problems occur,
switch the unit off and disconnect it from the power
supply.
࡙In order to prevent electric shocks, fires or injuries,
always stop the unit, disable the protection switch
and contact SAMSUNG’s technical support if the unit
produces smoke, if the power cable is hot or damaged
or if the unit is very noisy.
࡙Always remember to inspect the unit, electric
connections, refrigerant tubes and protections
regularly. These operations should be performed by
qualified personnel only.
࡙The unit contains moving parts, which should always
be kept out of the reach of children.
࡙Do not attempt to repair, move, alter or reinstall the
unit. If performed by unauthorized personnel, these
operations may cause electric shocks or fires.
࡙Do not place containers with liquids or other objects
on the unit.
࡙All the materials used for the manufacture and
packaging of the air conditioner are recyclable.
࡙The packing material and exhaust batteries of the
remote controller(optional) must be disposed of in
accordance with current laws.
࡙The air conditioner contains a refrigerant that has
to be disposed of as special waste. At the end of its
life cycle, the air conditioner must be disposed of in
authorised centres or returned to the retailer so that it
can be disposed of correctly and safely.
࡙Do not use means to accelerate the defrost operation
or to clean, other than those recommended by
Samsung.
࡙Do not pierce or burn.
࡙Be aware that refrigerants may not contain an odour.
Safety Information
