Page 1/12
1
Package Contents
17” TM/LM- E 7117
Standalone Monitor (x 1) ……………….
VGA Cable………………………..(x 1)
USB type A to B cable...……….....(x 1)
Power Cord………………………..(x 1)
12V/40 Power Adapter .(x 1) W ………...
User Manual (x ……………………… 1)
Product Features
17” TFT LCD panel
LCD resolution up to 1 x 1024 280
5-wire resistive or IR touch panel for TM- 7117E
Easy tilt angle adjustment from 15 to 70 ˚ ˚
2 x USB port support
Optional side attachment support (SD-466Z or KP-300W)
Optional VESA mounting kit (WB-6000V- B)
Dimension : mm (H) x mm (W) x mm (D); 401 385 286
Weight : 6.82 kg
19630902010 Ver. Original
http://www.posiex.com
/LM-7117E TM
Standalone POS Monitor
User Manual
2
Views of the TM/LM-7117E
Front View
Rear View
Bottom View
Side Mount Cover
Release Button
Cable Exit
17 - LCD Panel ”LM 7117E
17 - E Resistive or IR Touch Panel ”TM 7117
LED Indicator
Cable Holder
Cable Groove
Rubber Feet with Fixing Screw
Cable Passage
Gen 5 Base
Cable Cover
Rubber Feet with Fixing
3
Left-Side View
Right-Side View
I/O Ports
VGA Port
USB (Type B) Port
DC-IN Power Jack
USB (Type A)
OSD button
E button XT
＋ button
－ button
Tilt Adjustment Lever
OSD Control Button
Power button
