6”/150MM 2-WAY SPEAKER SYSTEM SUITABLE
FOR SELECT AUDI/SEAT/SKODA/VW VEHICLES
Model: ZDSW6CS
• includes 1” Silk Domed Tweeter
• 6” Midrange Speaker
• 2-Way Component System
•120W Max Power Output
• 12dB Crossover
• Ferrite Motor
• Neodymium Tweeter
• Plug and Play
SPECIFICATIONS
All specications subject to change without notice.
ZD
© 2021 Phoenix Gold | A Brand of AAMP Global
www.phoenixgold-eu.com
ZDSW6CS - 6”/150mm 2-Way Component Speaker System
Installation
Remove the door cover of the preferred mounting site. Disconnect the original speaker/tweeter and place in storage.
Connect the new speaker/tweeter and use pre-existing screws to x rmly into place.
Make sure the enclosure is rmly xed in your vehicle. Check before drilling or cutting holes. DO NOT work near fuel
tanks, fuel lines hydraulic lines or electrical wiring.
DO NOT mount speaker or tweeter in such a way as to pinch or damage the wires.
SPECIFICATION ZDSW6CS
Speaker 6” two way system
Max Power (Watts) 120 Watts
RMS Power (Watts) 60 Watts
Filter 12dB
Magnet Neodymium (Tweeter) / Ferrite (Speaker)
Speaker Material Composite Paper Cone
Tweeter Material Silk
Connection Plug & Play
REV 01/10/21
Vehicle Make/Model Chassis Years Front
Location
Rear
Location
SEAT Altea 5P-5PN 2004 - 2015 Yes -
SEAT Altea XL 5P-5PN 2006 - 2015 Yes -
SEAT Arona KJ7 2018 - 2022 Yes -
SEAT Arosa 6H-6HS 1997 - 2004 Yes -
SEAT Cordoba (II) 6L 2002 - 2009 Yes -
SEAT Ibiza (III) 6L 2001 - 2008 Yes -
SEAT Leon (I) 1M 2000 - 2005 Yes -
SEAT Leon (II) 1P 2006 - 2012 Yes -
SEAT Mii AA-AAN 2012 - 2020 Yes -
SEAT Toledo (II) 1M 1999 - 2004 Yes -
SEAT Toledo (III) 5P 2004 - 2009 Yes -
SEAT Toledo (IV) KG 2012 - 2019 Yes -
Compatibility
© 2021 Phoenix Gold • www.phoenixgold-eu.com
Compatibility
ZDSW6CS - 6”/150mm 2-Way Component Speaker System
Vehicle Make/Model Chassis Years Front
Location
Rear
Location
Audi A2 8Z 1999 - 2005 Yes -
VW Amarok 2H 2010 - 2021 Yes -
VW Bora 1J 1998 - 2005 Yes -
VW Bora Variant 1JM 1999 - 2005 Yes -
VW C-Trek 1J - 2016 Yes -
VW Caddy - 2020 Yes -
VW Golf (IV) 1J1-1JM 1997 - 2004 Yes -
VW Golf Variant (IV) 1J1-1JM 1997 - 2004 Yes -
VW Golf (VI) 1K-1KM 2008 - 2014 Yes Yes
VW ID3 - 2021 Yes -
VW ID4 - 2021 Yes -
VW Lavida 2008 - 2018 Yes Yes
VW Lavida Plus 0C - 2018 Yes Yes
VW Lupo 6E-6ES-6X 1998 - 2005 Yes -
VW New Beetle 1C-1Y 1997 - 2011 Yes -
VW Passat B5-B6-B7 1996 - 2015 Yes -
VW Passat CC 2008 - 2016 Yes Yes
VW Passat Variant 1997 - 2005 Yes -3B+-3BG
VW Polo (IV) 9N-9N3 2001 - 2009 Yes -
VW Polo (V) 6R Yes -
VW Polo (VI) 2G 2009 - 2016 Yes -
VW Sagitar(II/III) A5-A6 - 2010 Yes -
VW Santana A05 2012 - 2020 Yes -
VW Scirocco (III) 2008 - 2017 Yes -
VW Multivan T6.1 - 2019 Yes -
VW Tiguan (I) 5N 2007 - 2016 Yes Yes
VW Up/E-Up 2011 - 2020 Yes -
