Omega OG91XA Manual
Read below 📖 the manual in Italian for Omega OG91XA (12 pages) in the Oven category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users
Page 1/12
installation
and operating
instructions
OG91XA
cooktop
Dear customer,
We thank you and congratulate you on
your choice.
This new carefully designed product,
manufactured with the highest quality
materials, has been carefully tested to sa-
tisfy all your cooking demands.
We would therefore request you to read
and follow these easy instructions which
will allow you to obtain excellent results
right from the start.
May we wish you all the very best with
your modern appliance!
THE MANUFACTURER
APPLIANCE CONCEIVED FOR DOMESTIC USE IS
ONLY. THE MANUFACTURER SHALL NOT IN ANY
WAY BE HELD RESPONSIBLE FOR WHATEVER
INJURIES OR DAMAGES ARE CAUSED BY
INCORRECT ,INSTALLATION OR BY UNSUITABLE
WRONG OR ABSURD USE .
- The appliance is not intended for use by young children or infirm
persons without supervision.
- Young children should be supervised to ensure that they do not play
with the appliance.
- If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
- If a stationary appliance is not provided with a supply cord and a plug
or with other means for disconnection from the supply having an air gap
contact separation in all active (phase) conductors, the instructions shall
state that such means for disconnection shall be incorporated in the fixed
wiring according to the wiring rules.
3
Fig. 1
wok Ø 20-32
fast Ø 20-26
semifast Ø 14-20
auxiliary Ø 10-14
INSTRUCTIONS FOR USE
FOR VITROCERAMIC HOBS SEE ADDITIONAL INSTRUCTIONS
Installation
All the operations concerned with the installation (electrical connection) must be
carried out by qualified technicians, in terms with the standards in force.
For specific instructions, kindly read the part reserved for the installation technician.
Use
Gas burners (Fig. 1-1a-1b).
The ignition of the gas burner is carried out by putting a small flame to the upper part
holes of the burner, pressing and rotating the corresponding knob in an anti-clockwise
manner, until the maximum position has coincided with the marker. When the gas
burner has been turned on, adjust the flame according to need. The minimum position
is found at the end of the anti-clockwise rotation direction.
In models with automatic ignition, operate the knob as described above, pressing
simultaneously, the corresponding push-button. The electric spark between the
ignition plug and the burner provides the ignition of the burner itself. After ignition,
immediately release the push-button and adjust the flame according to need.
To start the burner in models equipped with a thermoelectric resistance keep the knob
pressed hard for 10 seconds, as described above, after placing it on its maximum value.
After releasing the knob, make sure the burner is actually lit.
N.B. - we recommend the use of pots and pans with a diameter matching that of the
burner, thus preventing the flame from escaping from the bottom part and
surrounding the pot
- do not leave any empty pots or pans on the fire
- do not use any tools for grill-cooking on Crystal hobs.
When cooking is finished, it is also a good norm to close the main gas pipe tap and
cylinder.
GAS
Product Specifications
| Brand: | Omega |
| Category: | Oven |
| Model: | OG91XA |
