Transmitter - front view
Transmitter - rear view
Receiver - front view
Receiver - rear view
Thank you for purchasing the Luxi Electronics® Presenter product. Please read through this manual before using the product.
How the product functions: Think of the daisy chain as the ow of a river; each transmitter (Tx) connects to a source device and loads
the signal to the river ow; each receiver (Rx) unloads the signal from the river ow and sends it to the display it is connected to.
The front panel and the RS-232 controls determine which source signal goes to which display.
Power options:
This product can draw power from other Presenter products in the chain
or from an optional external power supply.
TX TX RX RX
CAT 5, 6, 7
TITEL 01
System diagram
P R E S E N T E R ™
Quick S t a r t Guide
HDMI Input
Power
Power
RS232
HDMI Output
Daisy Chain
Input
Daisy Chain
Input
Daisy Chain
Output
Ethernet
Daisy Chain
Output
Ethernet
Show Me
RS-232 Status LED
Status LED
SHOW ME
Button
© PureLink GmbH 2013
I n n o v a t i o n G e r m a n E n t e r p r i s e s .
K n o w - H o w . Q u a l i t y . D e s i g n .
PureLink GmbH | Von-Liebig-StraĂźe 10 | 48432 Rheine | Germany | Tel.: 0049 (0)5971-800 299-0 | Fax: 0049 (0)5971-800 299-99 | E-mail: info@purelink.de | Internet: www.purelink.de
P R E S E N T E R ™
Quick S t a r t Guide
Please contact your reseller directly for local support.
See PureLink website for RS-232 commands and user manuals.
One Tx and one Rx connected with a short Cat6 cable. Use the
minimum system to test all devices and cables to be used in bigger
systems rst in order to isolate any potential problems.
Minimum system Support
TRANSMITTER control options RECEIVER control options
Pressing the “Show Me” button on the front panel will select the
source connected to this Tx unit; all displays will show the same
content from this Tx box. An external button can be connected to the
“Show Me” port on the rear panel. A RS-232 host connected to the
rear panel can control all functions of every unit in the chain. Make
sure both DIP switches recessed on the bottom side are in the down
(o) position.
A RS-232 host connected to the rear panel can control all functions of
every unit in the chain. Make sure both DIP switches recessed on the
bottom side are in the down (o) position.
The captive screw plugs for power, RS-232 and contact controls are
supplied with the unit. Separate the wires about 2.5 cm long; strip o
the wire insulation precisely 5 mm from the end.
Identify the positive and negative leads for power; Luxi power supply
has a white stripe on the positive wire. If not sure, use a multi meter
to verify.
Captive screw plug termination Captive screw plug termination
For providing a system wide internet access. Be very careful NOT to
plug the Ethernet cable into the yellow 100s connector or vice versa!
Permanent damage may occur.
This Presenter is selected.
This Presenter is not
selected.
Communication error.
Ethernet port Front panel LED
Follow the standard
EIA 568B pin out.
RJ45 plug termination
1
2
3
4
5
6
7
8
RJ45 EIA 568B
