Page 1/30
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E- -Mail: info@kern sohn.com
Phone: +49- - -0 [0]7433 9933
Fax: 9933 149 - -+49 [0]7433 -
Internet: - www.kern sohn.com
Operating manual
Compact balance
KERN FXN
Version 1.5
201 088-
GB
FXN-BA-e-1815
2 - -e- FXN BA 1815
GB
KERN FXN
Version 1.5 8- 201 08
Operating manual Compact balance
Contents
1 Technical data ............................................................................................ 3
1.1 Dimensions ............................................................................................................................. 5
2 Appliance overview .................................................................................... 6
2.1 Overview of display ................................................................................................................ 6
2.2 Keyboard overview ................................................................................................................. 7
3 Basic Information (General) ...................................................................... 8
3.1 Proper use .............................................................................................................................. 8
3.2 Improper Use ......................................................................................................................... 8
3.3 Warranty ................................................................................................................................. 8
3.4 Monitoring of Test Resources ................................................................................................ 8
4 Basic Safety Precautions .......................................................................... 9
4.1 Pay attention to the instructions in the Operation Manual ..................................................... 9
4.2 Personnel training .................................................................................................................. 9
5 Transport and storage ............................................................................... 9
5.1 Testing upon acceptance ....................................................................................................... 9
5.2 Packaging / return transport ................................................................................................... 9
6 Unpacking, Setup and Commissioning.................................................. 10
6.1 Installation Site, Location of Use .......................................................................................... 10
6.2 Unpacking and placing ......................................................................................................... 11
6.2.1 Scope of delivery .................................................................................................................. 12
6.3 Battery operation .................................................................................................................. 12
6.4 Initial Commissioning ........................................................................................................... 14
7 Adjustment ............................................................................................... 14
7.1 Adjusting ............................................................................................................................... 14
7.1.1 Adjustment ........................................................................................................................... 15
7.1.2 Verification............................................................................................................................ 16
8 Operation .................................................................................................. 18
8.1 Weighing .............................................................................................................................. 18
8.2 Taring ................................................................................................................................... 18
8.3 Parts counting ...................................................................................................................... 19
9 The menu .................................................................................................. 21
9.1 Navigation in the menu ........................................................................................................ 21
9.2 Menu overview ..................................................................................................................... 22
9.3 Display background illumination .......................................................................................... 23
9.4 Automatic switch off function Auto- - Off................................................................................. 24
9.5 Checkweighing ..................................................................................................................... 25
9.6 Reset to factory setting ........................................................................................................ 27
9.7 Hold function ........................................................................................................................ 28
10 Error messages ........................................................................................ 29
11 Instant help ............................................................................................... 29
12 Servicing, maintenance, disposal ........................................................... 30
12.1 Cleaning ............................................................................................................................... 30
12.2 Servicing, maintenance ........................................................................................................ 30
12.3 Disposal ................................................................................................................................ 30
13 Declaration of Conformity ....................................................................... 30
FXN- -e- 3BA 1815
1 Technical data
KERN FXN
3K- 4N
FXN
6K 3N-
FXN
10K 3N-
FXN
30K 3N-
Weighing range (max) 3 kg 6 kg 15 kg 30 kg
Readability (d) 5 g 0.5 1 g g 5 g
Reproducibility g 1 g 0.5 5 g 5 g
Linearity 5 g 2 g 10 g 0 g 1
Recommended adjustment
weight, not added (class)
3 kg
(M1)
6 kg
(M1)
15 kg
(M3)
30 kg
(M1)
Stabilization time (typical) 2 sec.
Units g, kg, lb, oz,
Warm- up time 10 min.
Electric Supply Battery operation: 4 x 1.5V Size D
Auto-Off (rechargeable
battery) 15 min., 5 min., 3 min., off
Display type LCD, digit height 25 mm
Operating temperature 0° C …. + 40° C
Humidity of air - 25 % 95 % (non-condensing)
Dimensions of weighing
plate
(Stainless steel) (mm)
236 x 195
Casing dimensions 240 x 280 x 120
Dimensions, completely
assembled (mm) 240 x 280 x 120
Weight kg (net) 3.1
IP protection IP68 to DIN 60529
