Hercules XPS 2.0 Lounge Manual
Read below 📖 the manual in Italian for Hercules XPS 2.0 Lounge (8 pages) in the Speaker category. This guide has been helpful for 7 people and has been rated 4.5 stars on average by 2 users
Page 1/8
ITALIANO DEUTSCH ESPAÑOL NEDERLANDS ENGLISH FRANÇAIS
XPS 2.0 Lounge
TABLE OF CONTENTS
1. INTRODUCTION................................................................................................................ 2
1.1. Box contents ............................................................................................................... 2
1.2. Technical specifications.............................................................................................. 2
1.3. Recommended use..................................................................................................... 3
2. INSTALLING THE XPS 2.0 LOUNGE SPEAKER KIT...................................................... 3
2.1. Positioning the speaker kit.......................................................................................... 3
2.2. Connections................................................................................................................ 4
2.2.1. Connection to a PC......................................................................................... 6
2.2.2. Connection to a television set equipped with a headphone plug.................... 6
2.2.3. Connection to a DVD player / television set equipped with Left and
Right audio outputs ......................................................................................... 6
2.2.4. Connection to a game console ....................................................................... 6
3. USING THE XPS 2.0 LOUNGE SPEAKER KIT................................................................ 7
4. TECHNICAL SUPPORT .................................................................................................... 7
5. WARRANTY....................................................................................................................... 8
ENVIRONMENTAL PROTECTION RECOMMENDATION......................................................... 8
ITALIANO DEUTSCH
Русский NEDERLANDS ENGLISH FRANÇAIS ESPAÑOL
XPS 2.0 Lounge
2/8 – User Manual
1. INTRODUCTION
1.1. Box contents
2 amplified satellite speakers
1 remote control + 1 iPod / ZuneTM adapter
User Manual
1.2. Technical specications
Total RMS power
(effective power)
Satellite speakers: 2 x 2.5W RMS
Total peak power 5W RMS
Frequency response Satellite speakers: 60 – 20KHz
Magnetic shielding Magnetically shielded, allowing for placement close to a monitor
without disturbing the display
Features Right speaker:
- 1 female RCA audio output to connect the left speaker
- 1 power cord
- 1 cable connected to the remote control
Remote control:
• 1 master volume control knob
• 1 treble volume control knob
• 1 stereo headphone output
• 1 microphone input
• 1 LINE IN input for CD/MP3 player...
• 1 audio source selection button
• 1 adapter to connect iPod and ZuneTM
For use with DVDs, games, CD-Audio, MP3
ITALIANO DEUTSCH ESPAÑOL NEDERLANDS ENGLISH FRANÇAIS
Русский
XPS 2.0 Lounge
User Manual – 3/8
1.3. Recommended use
- Place the satellite speakers on a flat surface to prevent them from falling.
- Never open up your speaker kit, as you risk damaging its internal components.
- To avoid the risk of fire or electrical discharge, keep your speaker kit away from:
- rain or humidity, as well as all fluids (water, chemical products and any other liquids),
- sources of heat such as heaters, stoves or any other heat-producing devices (including
amplifiers),
- direct sunlight.
- Unplug your speaker kit’s power cord if you do not plan on using it again for an extended period
of time. To disconnect the power cord, be sure to pull on the plug. Never pull on the cord itself.
Warning: Even when in standby mode, this device consumes electricity (4W)
- Ensure that the speaker kit’s power cord remains easily accessible once connected to the power
supply.
- Disconnect the speaker kit before cleaning. Use a damp cloth for cleaning and avoid the use of
aerosols.
2. INSTALLING THE XPS 2.0 LOUNGE SPEAKER KIT
2.1. Positioning the speaker kit
1. Position the satellite speakers on a desk to either side of your monitor, keeping them at least
50cm away from the side walls.
2. Place the satellite speakers at an equal distance from the listener and direct them towards the
listening position.
