Page 1/12
Owner’s Manual
Havis Docking Station For the
Havis iPad Protective Case
www.havis.com
1-800-524-9900
DS-APP-102
DS-APP-112
PKG-DS-APP-102
PKG-DS-APP-112
PKG-DS-APP-132
PKG-DS-APP-142
DS-APP-100 Series
DS-APP-102
DS-APP-112
PKG-DS-APP-102
PKG-DS-APP-112
PKG-DS-APP-132
PKG-DS-APP-142
Before Beginning (Original Instructions)
2
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-APP-100 Series Docking Station for
the Havis iPad Protective Case.
For questions regarding the set-up of your DS-APP-100 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
Supplying Power to iPad
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
Havis Product Apple iPad Model(s) Compatible
Havis Products
DS-APP-102 All
(2, 3, 4, Air, Air 2, & Pro 9.7)
DS-DA-701
DS-DA-702
DS-DA-704
DS-DA-705
DS-APP-112 Air, Air 2, & Pro 9.7 DS-DA-705
DS-DA-701 iPad 2 & 3 DS-APP-102
DS-DA-702 iPad 4 DS-APP-102
DS-DA-704 Air & Air 2 DS-APP-102
DS-DA-705 Air, Air 2, & Pro 9.7 DS-APP-102
DS-APP-112
PKG-DS-APP-102
(includes DS-APP-102 & DS-DA-701) iPad 2 & 3 n/a
PKG-DS-APP-112
(includes DS-APP-102 & DS-DA-702) iPad 4 n/a
PKG-DS-APP-132
(includes DS-APP-102 & DS-DA-704) Air & Air 2 n/a
PKG-DS-APP-142
(includes DS-APP-112 & DS-DA-705) Air, Air 2 & Pro 9.7 n/a
www.havis.com • 1-800-524-9900
Table of Contents
3
Specications
Port Replication Capability
Parts Included
Installation
Cable Management
Operation - Docking
Operation - Undocking
Supplying Power to iPad
3
4
4
6
8
9
10
11
Specications
Power Supply Input 12.0 V DC-In
Dimensions 10.8” ( 27.5 cm) H x 6.9” ( 17.6 cm ) W x 3.1” ( 8.0 cm ) D
Weight 1.6 lbs ( 0.68 kg )
Operating Environment 0° C to 35° C ( 32° F to 95°F )
Storage Environment -40° C to 85° C ( -40° F to 185° F )
• Do not place metal objects or containers of liquid on top of the Docking Station
• If a malfunction occurs, immediately unplug the Power Supply and remove the tablet
• Do not store the Docking Station where water, moisture, steam, dust, etc. are present
• Do not connect cables into ports other than what they are specied for
• Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F)
for a long period of time
Precautions
EC DECLARATION OF CONFORMITY in accordance with EN 45014
Manufacturers Name: Havis, Inc.
Manufacturers Address: 75 Jacksonville Road, Warminster, PA 18974 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Havis iPad Protective Case
Model: DS-APP-1XX, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
EMC Directive 2004/108/EC: EN 55022:2010, Class B, Information technology equipment -
Radio disturbance characteristics - Limits and methods of measurement
EN 55024:2010, Information technology equipment - Immunity characteristics -
Limits and methods of measurement
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
BS EN 50498:2010: Section 7, after market electronic equipment in vehicles.
Supplementary Information:
The product herewith complies with the requirements of the EMC Directive 2004/108/EC. This product requires the
use of the provided e-Marked automotive power supply when used within vehicles.
Plymouth twp, MI, USA March 14, 2014 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modications
to the model DS-APP-1XX not expressly approved by Havis, Inc. could void
the user's authority to operate this equipment.
