Diusore acustico operante sia a 8Ω che a 100V, destinato ad impianti di
lodiusione. L’alta qualità dei componenti utilizzati per la sua realizzazione
garantisce un’ottima resa acustica.
L’installazione di questo prodotto deve essere eettuata esclusivamente da
tecnici specializzati, competenti di impanti elettrici e di sonorizzazione.
In caso di installazione o collegamenti errati il produttore non si assume
alcuna responsabilità per danni a persone o cose.
Riferitevi alle gure sottostanti (g.1-2) per il corretto
collegamento dei cavi. Prima di procedere con l’installazione
assicuratevi che l’amplicatore sia spento. Durante il
funzionamento sui morsetti di collegamento è presente una
tensione che potrebbe essere pericolosa.
Conservate il manuale di istruzioni per utilizzi futuri. Utilizzate la staa in
dotazione per il corretto posizionamento a parete o sotto.
A. Cablaggio 8Ω
Se volete utilizzare il diusore per un impianto a impedenza, collegate il
connettore rosso (+) e quello nero (-) alla presa di uscita dell’amplicatore.
Nel caso dobbiate collegare più diusori, dopo aver vericato la potenza
totale, dovrete sfruttare collegamenti in serie o in parallelo (g.1) allo scopo di
ottenere un’impedenza nale supportata dall’amplicatore (in genere 4-16Ω).
Il selettore andrà posto su 8Ω.
Impedenze errate possono danneggiare seriamente gli
apparecchi connessi.
B. Cablaggio 100V
Per il collegamento a impianto in tensione costante, collegate il morsetto nero
del diusore alla presa “COM” dell’amplicatore, mentre il morsetto rosso del
diusore andrà connesso alla presa 100V dell’amplicatore.
Nel caso dobbiate collegare più diusori, dopo aver vericato la
potenza totale, potrete connetterli all’amplicatore con un collegamento
in“parallelo”(g.2).
Ricordatevi di valutare la corretta sezione dei cavi da utilizzare in relazione
alla distanza dei diusori dall’amplicatore.
Il selettore andrà posto su 100V.
Considerate correttamente la potenza dei diusori e
dell’amplicatore al quale sono collegati: la somma
della potenza dei diusori non deve superare la potenza
dell’amplicatore.
C. Conformità, garanzia e assistenza
II marchio CE indica che il prodotto è conforme ai requisiti essenziali delle
direttive europee e relative norme ad esso applicabili.
Il prodotto è coperto da garanzia in base alle vigenti normative nazionali ed
Europee.
Per le condizioni complete di garanzia e per eettuare richieste di assistenza
visitate il sito internet: www.glemm.eu. Vi suggeriamo anche di procedere alla
registrazione del prodotto, loggandovi nell’area riservata del sito. Avrete così
la possibilità di ricevere aggiornamenti e informazioni sui nostri articoli.
Audio speaker operating both 8Ω than 100Vand intended for PA SYSTEM.
The high quality of the components used for its construction guarantees an
excellent acoustic performance.
The installation of this product must be carried out exclusively by specialized
technicians, skilled in electric and audio systems.
In case of wrong installation or connections, the manufacturer doesn’t take
any responsibility for damages to people or objects.
Refer to the below pictures (g.1-2) for correct cable
connection. Before starting the installation, make sure that the
amplier is turned o. The voltage present on the terminals
during operation could be dangerous.
Keep the instruction manual for future reference. Use the included bracket for
correct wall or ceiling placement.
A. 8Ω wiring
If you wish to use the speaker for a constant impedance system, put the red
(+) and black (-) wires into the amplier’s output socket.
If you need to connect more than one speaker, after checking the total power,
you can make series or parallel connections (pict. 1) in order to obtain a nal
impedance supported by the amplier (usually 4-16Ω).
The selector is to be put on 8Ω.
Wrong impedances could seriously damage the connected
xtures.
B. 100V wiring
For the connection of the speaker to a constant voltage system, connect
the speaker’s black terminal to the “COM” socket of the amplier, while the
speaker’s red terminal is to be connected to the 100V socket of the amplier.
If you need to connect more than one speaker, after checking the total power,
you can connect them to the amplier with a “parallel” connection (picture 2).
Remember to consider the correct section of the cables, according to the
distance of the speakers from the amplier.
The selector is to be put on 100V.
Consider carefully the power of the speakers and of the
amplier to which they are connected: the total power of the
speakers must not exceed the amplier’s power.
C. Compliance, warranty and service
The CE brand indicates that the product complies with the essential
requirements of the applicable European directives and related standards.
The product is covered by warranty according to current national and
European regulations.
For complete warranty conditions and for technical service requests visit the
website: www.glemm.eu. We also suggest to register your product, by logging
into the website’s private area. In this way you will have the possibility to
receive updates and information on our items.
Caratteristiche tecniche / Technical specications
Potenza Massima / RMS
Max power/ RMS power
160W / 80W RMS
Altoparlante / Speaker Woofer 8” / Tweeter 2”
Impedenza / Impedance
Tensione / voltage
8Ω
100V
Risposta in frequenza
Frequency response
65Hz - 20KHz
Inclusi / Included Staa di ssaggio / Bracket
Dimensioni / Dimensions 280 x 435 x 240mm (l x h x p)
Peso / Weight 6,8 Kg
154 - Made in P.R.C.
PRODOTTO DA / PRODUCED BY:
KARMA ITALIANA Srl
Via Gozzano 38/bis
21052 Busto Arsizio (VA)
www.karmaitaliana.it
g.1 g.2
Lo smaltimento del prodotto deve
essere eettuato conferendolo
ad un apposito centro di raccolta
dierenziata (Dir. 2012/19/UE).
www.glemm.eu
Esempio: Casse= 41W Ampli= 100W
Example: Speakers = 41W Ampli = 100W
OK !
com
100V
15W 10W 10W 6W
Totale = 8Ω con potenza totale di 200W
Total = 8Ω with 200W total power
2 di x 8 4 di x 4 = 16 = 16
8Ω 4Ω
4Ω
4Ω
4Ω
8Ω
50W
50W
25W
25W
25W
25W
23.1
The manufacturer, in order to improve its products, reserves the right to modify the characteristics
whether technical or aesthetic, at any time and without notice.
Il fabbricante, allo scopo di migliorare i propri prodotti, si riserva il diritto di modicarne le
caratteristiche siano esse tecniche o estetiche, in qualsiasi momento e senza alcun preavviso.
BRACKET
VOLT
100 8ABS
100V
8
SELECTOR
160
WBLACK
