Page 1/40
MONO CLASS D AMPLIFIER
SXE1200.1D
SXE2000.1D
VERS.1.1
2
INHALTSVERZEICHNIS
TABLE OF CONTENT
TABLE DES MATIÈRES
SOMMARIO
INDICE
BEDIENUNGSANLEITUNG
USER’S MANUAL
MODE D’EMPLOI
MANUALE D´USO
MANUAL DE USO
3
9
15
21
27
ABBILDUNGEN / FIGURES / FIGURES / FIGURI / FIGURES 34
3
Bitte lesen Sie die Bedienungsanleitung vollständig durch, bevor Sie mit der Instal-
lation beginnen und den Verstärker in Betrieb nehmen.
TECHNISCHE DATEN
Ausgangsleistung RMS
Ausgangsleistung Max.
Lautsprecherimpedanz
Frequenzgang
Klirrfaktor
Signalrauschabstand
Eingangsempîš¿ndlichkeit
Eingangsimpedanz
Tiefpassîš¿lter
Subsonicîš¿lter
Bass Boost
Phasenregler
Master/Slave Link
Hochpegeleingänge
Automatische Einschaltfunktion
Betriebsspannung
Sicherung
Abmessungen (B x H x L)
1 x 300 W @ 4 Ohm
1 x 450 W @ 2 Ohm
1 x 600 W @ 1 Ohm
1 x 600 W @ 4 Ohm
1 x 900 W @ 2 Ohm
1 x 1200 W @ 1 Ohm
1 – 8 Ohm
10 – 160 Hz (-3 dB)
< 0,5 % (80 Hz)
> 105 dB
0,2 – 5 V
10 kOhm
40 – 150 Hz @ 12 dB/Oktave
10 – 35 Hz @ 12 dB/Oktave
0 – 12 dB @ 40 Hz
0 – 180°
Ãœber Master Out
Per beiliegendem Kabelstecker
Nur über Hochpegeleingänge
+12 V (9 – 15 V), Minus an Masse
3 x 25 A
220 x 53 x 268 mm
1 x 400 W @ 4 Ohm
1 x 700 W @ 2 Ohm
1 x 1000 W @ 1 Ohm
1 x 800 W @ 4 Ohm
1 x 1400 W @ 2 Ohm
1 x 2000 W @ 1 Ohm
1 – 8 Ohm
10 – 160 Hz (-3 dB)
< 0,5 % (80 Hz)
> 105 dB
0,2 – 5 V
10 kOhm
40 – 150 Hz @ 12 dB/Oktave
10 – 35 Hz @ 12 dB/Oktave
0 – 12 dB @ 40 Hz
0 – 180°
Ãœber Master Out
Per beiliegendem Kabelstecker
Nur über Hochpegeleingänge
+12 V (9 – 15 V), Minus an Masse
3 x 30 A
220 x 53 x 328 mm
Technische Änderungen vorbehalten
SXE1200.1D SXE2000.1D
