Commercial

Brugervejledning User Instructions Gebrauchsanweisung G GB

Mode d‘emploi Instrukcja obslugi G GB

PYC

DK D

F PL

Ðóêîâîäñòâî ïî Ýêñïëóàòàöèè

Commercial Freezer/Cooler

Operating instructions

Before you start reading this manual, please

pay attention to the last page showing

pictures and reference numbers.

Operation

To get the max. advantage from your freezer/

cooler it is important that it is placed in the

correct position. You should therefore read

this manual carefully. Keep the manual in

a place where it can always be found for

reference. Even with careful attention to

the freezer, a mishap may occur, with the

consequence that the contents of the cabinet

could be lost, therefore contents insurance is

recommended.

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they

have been given supervision or instruction

concerning use of the appliance by a person

responsible for their safety. Children should

be supervised to ensure that they do not play

with the appliance.

Placing the freezer/cooler

The freezer/cooler should not be placed

where it might be splashed by water, in

extremely high humidity or in direct sunlight,

see drawing no 1. Any of these factors may

lead to a reduction in the performance and

shorten the life span of the components.

The freezer/cooler should be placed on a

horizontal level and it must not be placed

too close to a heating appliance or pipes. The

distances from the appliance should be in

accordance with the sketch no. 1.

Electricity Supply

The electricity supply should always be in

accordance with the rating plate on the back

of the freezer, see sketch 3, here you can read

the voltage(V) and frequency (HZ). The supply

must always be in accordance with the law

and regulation of the country with regards to

electrical safety. If you are in doubt ask your

supplier.

Starting Up

In case the compressor does not start when

the freezer/cooler has been plugged in, the

reason may be that the electricity supply to

the unit is not in order. Check if there is an

electricity supply to the plug or if the fuse is

blown.

Temperature adjusting

Temperature regulation is controlled by the

thermostat, see sketch no. 4. The control is

placed in the compressor compartment.

The higher the number on the dial the lower

the temperature. With some models the

temperature is displayed on the front of the

cabinet.

N.B. with a too low temperature in the

cabinet the power consumption will increase,

therefore check that the thermostat setting is

at a sensible level.

N.B. the stock placed in the cabinet should be

at a temperature of at least -20 degrees C., as

the appliance is not sold as a freezing down

unit, but is meant only to maintain frozen

stock. Warning if the stock you want to place

in the cabinet is only - 15 degrees C.

you risk damage to other items of stock

already in place. It will not help to place

the thermostat at a higher setting. The

temperature for coolers should be around + 4

degrees C.

Loading the freezer

Note: When placing stock in the freezer be

sure, that it is at a temperature of at least -20

degrees C. The contents must never be placed

above the load line, which is marked on the

inside of the cabinet – see sketch 5, otherwise

the contents cannot be kept at the tempe-

rature required for a conservator (-18C).

With coolers the temperature in the cabinet

should be approx. +4 degrees C. If you put too

many items in at one time, the cooler will not

be able to cool them before they are required.

Therefore it is recommended that small loads

are placed in the cabinet each time.

Glass lids

The glass lids on the freezer/cooler are as

vulnerable as any other glass item for scratches

and shock. Therefore you should never place

a glass lid directly on the oor if it is without a

frame. Also you should not place anything on

the glass which might scratch it, thus avoiding

damage or breaking the glass. The glass is

safety glass and can sustain pressure but not

scratches or shock.

N.B. There will be no compensation for

incorrect use.

Defrosting

In order for the freezer to work to its max.

eciency the cabinet should be defrosted

when it has about 2mm thick ice on the

sides. The ice is easily removed with a plastic

scraper. You must never use materials that may

damage the lining of the cabinet. Ice on the

lining is created by humidity and the frequent

use of the freezer. When defrosting, excess

water can be drained out by using the drain

water outlet on the front of the cabinet, see

sketch 6. Remember to close it after use.

Cleaning

Cleaning should be done when needed,

to ensure good performance with the min.

amount of energy consumption. If the freezer

is used in a dirty environment it should be

cleaned more frequently.

Cleaning can be done with a weak soap

solution.

Never use soda or an abrasive cleaning agent,

as these may damage the lining.

Standing freezer

If the freezer/cooler is unplugged and stored

for a period, the lid must be kept open for the

circulation of air in the cabinet. If there is no

circulation in the freezer/cooler the lining may

be stained. If the freezer has been stored for a

longer period, it should be properly cleaned as

described previously before being re-used.

Service

Before calling an engineer for the following

reasons:

1) Not freezing/cooling, - you should check if

there is an electricity supply to the cabinet (is

the fuse blown)?

2) Not freezing enough – check if the

contents have been placed in the box at the

right temperature (-20) (+4 cooler). Is the

vent clean? Is the cabinet correctly placed

with ventilation around the cabinet. Is the

thermostat setting correct?

If you have checked all the above, and still

have a problem, you should contact your

supplier.

If the supply cord is damaged, it must be

replaced by the manufacturer, it´s service

agent or similarly qualied persons, in order to

avoid a hazard.

For spare parts and extra items – contact your

supplier.

Product Specifications

Brand:	Elcold
Category:	Freezer
Model:	FOCUS 171
