Einhell PS 13 Niro Manual
Read below 📖 the manual in Italian for Einhell PS 13 Niro (1 pages) in the Heater category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/1
Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included
in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\2334234_01016.doc
Erstelldatum / create date: 12.10.2006 07:32:00 Aktualisiert / up dated: 24.10.2006
Patio Heater
Art.-No.: 23.342.34
PS 13 Niro
Bar code: 4006825531459
Sales unit: 1 pc
0085
(DVGW)
Features:
- Housing made of stainless steel
- Bottom made of power-varnished sheet steel
- Piezo ignition (1)
- Reflector (2) made of aluminium
- Burner (3)
- Regulator for continuously adjustment of heating
performance (4)
- Gas bottle cover (5)
- Mobile with castors (6)
- Thermoelectric ignition (not illustrated)
- Gas hose and regulator (not illustrated)
High eiciency terrace heating reector for cooler days and chilly evenings creates comfortable warmth.
The heating capacity can be adjusted continuously.
Technical data:
- Gas connection: p 28-30 / 37 mbar
- Type of gas: I
3
+ G 30
- Rated heat load max.: 12 KW (Hi) / 13 KW (Hs)
- Gas consumption max: approx. 0.946 kg/h
- Heating period: approx. 12 h at large operating
Using a 11 kg bottle
- Type of gas: propane/butane
- Height: approx. 2.23 mtrs.
- Reflector size: Ø approx. 79 cm
- Weight: 17.2 kg
- Packing dimensions: 790 x 400 x 790 mm
Made in Germany
2
3
4
1
5
6
Application area:
For commercial and private use, where ever comfortable warmth is required outdoor
during cold days and evenings.
The gas bottle can be stored in the base of the heater.
Instruction for
the commercial use:
In Germany, according to VBG 21 and TRF you have to apply a
hose faction protection in accordance with DIN 30 693 "Hose
faction protections for liqueed gas constructions", a tilt guard
and a safety pressure controller, if you use it in a commercial way
(e.g. at fair grounds).
Hose faction protection, tilt guard and safety pressure controller
do not belong to the scope of delivery.
In the countries of destination corresponding arrangements are
stringently to observe.
Product Specifications
| Brand: | Einhell |
| Category: | Heater |
| Model: | PS 13 Niro |
