TWO-CHANNEL AMPLIFIER
ŠŠŠ£Š„ŠŠŠŠŠŠ¬ŠŠ«Š Š£Š”ŠŠŠŠ¢ŠŠŠ¬
HTTPS://ALPHARD.AUDIO
CLASS AB
MLA-2160
1. Before installing the ampliļ¬er disconnect the battery from the electrical system.
2. To connect the ampliļ¬er it is necessary to stretch the power cable from the location of the battery to the place of installation
of the ampliļ¬er. Select the power cable with the appropriate regulations in AWG (see Table: Selection of the diameter of the
power cables)
3. Connect the power supply with the correct polarity. Connect all (+) terminals of the ampliļ¬er to the cables stretching from
the positive terminal of the battery and all (-) terminals of the ampliļ¬er ā to the cables stretching from the negative terminal of the
battery.
4. Place the fuse holder for each positive cable within 40 cm from the positive terminal of the battery and connect one end of
the power cable to the holder after connecting the other end to the ampliļ¬er. Do not install the fuse(s).
5. Route all signal cables next to each other and separately from the power cables.
6. Connect the wires of RCA input. The input signal power must be between 0.2 V and 6 V.
7 To connect the power wire supply is necessary to use special. power cables.
8. Fasten the ampliļ¬er properly when installing it in the vehicle. If the component is disconnected during driving, it may cause
serious damage to the passengers of the vehicle or another vehicle. It is not recommended to screw the ampliļ¬er directly to the
metal it can lead to distorsions at the signal outputs.
9. After installation is complete, check the wiring of the system and make sure that all connections have been made correctly.
Before installing the fuses, disconnect the positive lead from the battery and then install the fuse in the fuse holder. Using the
light bulb 12 V 21 W, connect the positive lead to one contact of the bulb and the other contact of the bulb to the positive
terminal of the battery.
When properly connected, the bulb must brieļ¬y light up and go out. Now you may connect the positive lead to the (+) of the
battery. If the light does not go out, then something is wrong. This will prevent damage to the ampliļ¬er in case of reverse polarity
and unwanted sparks when connecting. Install the rest of the fuses.
10 . To activate the ampliļ¬er, it is necessary to apply the positive potential of 12 volts to the control input of the ampliļ¬er (REM
IN) through a switch or a corresponding control output (REMOTE OUT) with the head unit (HU).
11 LED indicator on front of the ampliļ¬er turns . blue to indicate that the ampliļ¬er is turned on. If the indicator does not light
up see chapter "Possible faults and their solutions" for more information.
12. The sound level is calibrated by adjusting the volume of the source up to 3/4 of its maximum level. Then, adjust the
sensitivity level of the ampliļ¬er up until you hear distortions.
