LIGHTING THE WAY FOR SIXTY YEARS
ASSEMBLY INSTRUCTION MODEL #PAY-922-BF
WARNING:
Electrical Danger Turn Power Off
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
Y
ou will need 2-Candelabra Base Bulb
40Watts Recommended 60 Watts Max.
USE LED BULBS FOR EXTENDED USE
How to Install
UL
The fixture is damp rated
1.Install the mounting plate onto the outlet box using
two outlet box screws
2.Attach the backplate onto the mounting plate and
secure with screws.
3.Slide the candle sleeve over the socket.Slide
the shade over the candle sleeve.
LIGHTING THE WAY FOR SIXTY YEARS
ASSEMBLY INSTRUCTION MODEL #PAY-922-BF
Part Numbers
Part Number
Outlet Box
D
A
B C E
G
F
D. (2)-Screw
B. (2)-Outlet Box Screws
C. (3)-Wire Connector
A. (1)-Mounting plate
E.
(1)-Backplate(W5.5"xH7/8") XEH922BFBKP5.5IN
G. (1)-Fabric Shade(W5"xH6.25") XEH921SHA6.25IN
F. (1)-Metal Sleeve(Ø7/8"xH3.3") XEH921BFCDL3.3IN
