Page 1/2
L I G H T I N G T H E W A Y F O R S I X T Y Y E A R S
CRYST
WARNING:
Turn Power OffElectrical Danger
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
RAMA
ASSEMBLY INSTRUCTION MODEL #ORS-734-MG-ST
How to Install
1. Determine the preferred hanging
height and choose the correct length
of stems needed.
2. Slip the wires through the stems and
connect them together and place the
check ring over the threaded nipple on
top of the fixture body.Screw one end
of the stem assembly onto the fixture
body and the other end onto the
swivel on the canopy.
3. Attach mounting plate to the outlet
box using box screws and Connect
the fixture wires to the supply wires.
4. Mount the fixture to the outlet box
with ball nuts.
5. Place stone into the frame.
6. Install the bulb (Not included) in
accordance with the fixture s’
specifications. (DO NOT EXCEED
THE MAXIMUM WATTAGE RATING!)
7. Adjust the arms to the desired
placement.
This product can expose you to Lead,WARN ING:
which is known to the Sta te of Ca lifo rnia to cause cancer
and/or birth defects or reproductive harm. For more
information go to www.P65 Warnings.ca.gov
CSA841804HAMR2
Ø6"
You will need 4 - Candelabra Bulb
40 Watts Recommended 60 Watts Max.
USE LED BULBS FOR EXTENDED USE
This fixture is Dry Rated.
1"
54"
9"
12~54"
Crystorama.com
OUTLET BOX
A
Part Number
L I G H T I N G T H E W A Y F O R S I X T Y Y E A R S
CRYST RAMA
PART NUMBER MODEL #ORS-734-MG-ST
CSA841804HAMR2
B
D
GC
Part Numbers
A. Mounting Hardware
(3) - Wire connector
(1) - Mounting Plate
(2) - Box Screws
(1) - Grounding Screw
B. (2) - Ball Nuts; XVE733MGBANUT
C. (4) - Stone; 6-3/4" x H1/2";Ø
XVE733STONE
D. (1) - Canopy; 6" x H1";Ø
XVE734MGCAN6IN
E. (1) 6" Stem; XVE734MGSTEM6IN
F. (3) 12" Stem; XVE734MGSTEM12IN
G.(1) - Check ring.
Crystorama.com
E
