Page 1/2
ASSEMBLY INSTRUCTION MODEL # MAI-18606-GA
LIGHTING THE WAY FOR SIXTY YEARS
WARNING:
Electrical Danger
Turn Power Off
You will need 6- Candelabra Base Bulb
40 Watts recommended 60 Watts Max.
USE LED BULBS FOR EXTENDED USE
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes
HOW TO INSTALL:
Place the fixture parts on a soft cloth-covered
platform before installation of fixture.
3. Feed the wire through the Center Column Kit
and screw it onto the top of the Fixture Body Kit.
4. Screw the bottom nipple into the coupling on
the bottom of frame and then place the
bottom tubing and the bottom scroll kit,
in that order, over it.
Secure them with the finial.
1. Attach the mounting bar onto the outlet box.
2. Decide the desired hanging height and adjust
the chain to the correct length.
5. Raise the fixture up and do the wire connection.
Attach the canopy over the mounting bar and
secure with collar ring.
6. Dress the crystal as illustrated.
Crystorama.com
WARNING:This product can expose you to Lead,
which is known to the State of California to cause cancer
and/or birth defects or reproductive harm.For more
information go to www.p65warnings.ca.gov
The fixture is Damp rated
A
A
B
B
B
B
C
DD
E
108"
33 1/2"
28"
A. 6 Sets. (1)14mm + (4)12mm angle bead + (1)63mm crystal
Crystal Sets
B. 24 Sets. (1)12mm angle bead + (1)63mm crystal
C. 1 Sets. (4)12mm angle bead + (1)40mm ball
D. 12 Sets. (23)12mm angle bead
E. 12 Sets. (29)12mm angle bead
PART NUMBER MODEL# MAI-18606-GA
LIGHTING THE WAY FOR SIXTY YEARS
Part Number
Part Numbers
Crystorama.com
B. (1)-Canopy (W5 1/4"xH1")
-XSN18606GACAN5.25IN
C. (1)-Collar Ring
E. (1)-Chain (4mmx72")-XSN18606GACHA4MM
D. (1)-Collar Loop
A. (1)-Mounting hardware
Wire Connector × 2.
Mounting Bar × 1.
Mounting Screw × 2.
Washer × 1.
Nut × 1.
Threaded Nipple × 1.
A
Outlet Box
B
C
D
F
G
H
J
K
L
I
E
F. (1)-Center Column Kit
Fixture Loop x1.
9" Curved Strip Set x1.
Metal Box ; 12 holes ; Ø3 1/8" x1.
ROD ; H7" x1.
4" Curved Strip Set x1.
ROD ; H6" x1.
8" Curved Strip Set x1.
ROD ; H3" x1.
Center Nipple ; H19 1/4" x1.
G.(6)-Metal Candle Sleeve ; H4 1/8"
-XSN18606WHCDL4.125IN
H. (1)-Fixture Body Kit
Coupling x2.
Distributor Box ; Ø3 1/8" x1.
11 3/4" Arms x6.
Bobeche ; Ø2 3/8" x6.
Cup ; H1 1/2" x6.
Center Frame ; Ø17" x1.
12 holes on upper edge.
I. (6)-Medallion
J. (1)-Bottom Nipple ; H3 1/8"
K. (1)-Bottom Tubing ; H2"
L. (1)-4"Bottom Scroll Kit-XSN18606GASCR
M
M. (1)-Finial-XSN18606GAFIN
