Page 1/1
DETAIL A
DETAIL B
A
BB
A1) Remove Door from Chassis by removing
Top and Bottom Hinges. Keep screws,
discard hinges.
2) Attach customer supplied handle to Door Panel
using countersunk screws.
3) Screw Door Panel to Frame.
4) Slide Frame over Refrigerator door and attach
with 1 screw on each side, center of door.
5) Screw Bottom Pc to Door.
6) Attach Top Brace to Frame with 1 screw on side.
Attach Bottom Brace in the same manner.
7) Drill a hole thru the Top and Bottom Frame using
the Braces as a guide with a 5/32" drill bit. Install
screws to finish attaching the Top and Bottom
Braces securely to the Frame.
8) Drill a hole into the Door Panel from the top and
bottom using the Braces as a guide with a 1/4"
drill bit. Do not exceed 5/8". This is the hole that
the door will pivot on.
9) Remount the door using the supplied Top and
Bottom Hinges.
Top Hinge
Bottom Brace
Frame
Bottom
Pc
Step 7
Step 8 Top Brace
Instructions for
Integrated Frame
Summit Appliance
1-718-893-3900
(Built-In Application)
Door Panel
Hinge
or
Product Specifications
| Brand: | Accucold |
| Category: | Freezer |
| Model: | VT65MBIIFADA |
